SR-IOV NicClusterPolicy on Kubernetes: VF Config

SR-IOV (Single Root I/O Virtualization) lets you split a single physical network adapter into multiple Virtual Functions (VFs), each assignable to a pod as a dedicated network interface. For GPU workloads on Kubernetes, this means near-bare-metal network performance without the overhead of virtual bridges or software switching.

What Is SR-IOV and Why It Matters

A standard Kubernetes pod gets its network through a virtual bridge (CNI plugin like Calico or Cilium). This adds latency and limits throughput. SR-IOV bypasses the virtual bridge entirely:

• Physical Function (PF): the actual hardware NIC
• Virtual Functions (VFs): lightweight PCIe functions derived from the PF
• Each VF appears as an independent network device
• VFs are passed directly to pods via PCI passthrough
• Zero software overhead — the pod talks directly to the hardware

For AI training with NCCL or RDMA workloads, the difference between a bridged connection and an SR-IOV VF can be 30-50% higher throughput and significantly lower latency.

Prerequisites

• Kubernetes 1.27+ with Multus CNI installed
• NVIDIA Network Operator deployed
• Network adapters that support SR-IOV (Mellanox ConnectX-5/6/7)
• SR-IOV enabled in BIOS/UEFI (VT-d / IOMMU)
• Kernel with IOMMU support enabled

Verify SR-IOV support:

# Check if the NIC supports SR-IOV
lspci -vvv -s $(lspci | grep Mellanox | awk '{print $1}' | head -1) | grep -i "sr-iov"

# Check current VF count
cat /sys/class/net/ens3f0/device/sriov_numvfs

# Check maximum VFs supported
cat /sys/class/net/ens3f0/device/sriov_totalvfs

Configuring VFs in NicClusterPolicy

The NicClusterPolicy custom resource configures both MOFED drivers and SR-IOV VF creation:

apiVersion: mellanox.com/v1alpha1
kind: NicClusterPolicy
metadata:
  name: nic-cluster-policy
spec:
  ofedDriver:
    image: doca-driver
    repository: nvcr.io/nvidia/mellanox
    version: 24.07-0.6.1.0-0
  sriovDevicePlugin:
    image: sriov-network-device-plugin
    repository: ghcr.io/k8snetworkplumbingwg
    version: v3.7.0
    config: |
      {
        "resourceList": [
          {
            "resourcePrefix": "nvidia.com",
            "resourceName": "sriov_rdma_vf",
            "selectors": {
              "vendors": ["15b3"],
              "devices": ["101e"],
              "drivers": ["mlx5_core"],
              "isRdma": true
            }
          }
        ]
      }

Creating VFs with SriovNetworkNodePolicy

The SR-IOV Network Operator uses SriovNetworkNodePolicy to create VFs on specific nodes:

apiVersion: sriovnetwork.openshift.io/v1
kind: SriovNetworkNodePolicy
metadata:
  name: gpu-sriov-policy
  namespace: nvidia-network-operator
spec:
  nodeSelector:
    feature.node.kubernetes.io/pci-15b3.present: "true"
  resourceName: sriov_rdma_vf
  numVfs: 8
  nicSelector:
    vendor: "15b3"
    deviceID: "101b"
    pfNames: ["ens3f0"]
  deviceType: netdevice
  isRdma: true
  linkType: IB   # or ETH for Ethernet/RoCE

This creates 8 VFs on every node with a Mellanox NIC, each with RDMA capability.

Key Parameters

• numVfs: number of Virtual Functions to create per PF (max depends on NIC model, typically 64-128)
• deviceType: netdevice for kernel driver VFs, vfio-pci for DPDK/userspace
• isRdma: enable RDMA capability on VFs
• linkType: IB for InfiniBand, ETH for Ethernet (RoCE)
• nicSelector: target specific NICs by vendor, device ID, or PF name

Creating the Network Attachment

Define a SriovNetwork that pods can request:

apiVersion: sriovnetwork.openshift.io/v1
kind: SriovNetwork
metadata:
  name: gpu-sriov-network
  namespace: nvidia-network-operator
spec:
  resourceName: sriov_rdma_vf
  networkNamespace: ai-training
  ipam: |
    {
      "type": "whereabouts",
      "range": "192.168.100.0/24",
      "gateway": "192.168.100.1"
    }

This creates a NetworkAttachmentDefinition in the ai-training namespace that pods can reference.

Using SR-IOV VFs in GPU Pods

Request an SR-IOV VF alongside GPU resources:

apiVersion: v1
kind: Pod
metadata:
  name: gpu-training
  namespace: ai-training
  annotations:
    k8s.v1.cni.cncf.io/networks: gpu-sriov-network
spec:
  containers:
    - name: training
      image: nvcr.io/nvidia/pytorch:24.07-py3
      command: ["torchrun", "--nproc_per_node=8", "train.py"]
      resources:
        limits:
          nvidia.com/gpu: 8
          nvidia.com/sriov_rdma_vf: 1
      env:
        - name: NCCL_IB_DISABLE
          value: "0"
        - name: NCCL_NET_GDR_LEVEL
          value: "5"

The pod gets a dedicated SR-IOV VF as an additional network interface alongside the default cluster network.

Verifying VF Configuration

# Check VFs are created on the node
kubectl get sriovnetworknodestates -n nvidia-network-operator -o yaml

# Check available VF resources
kubectl get nodes -o json | jq '.items[].status.allocatable | to_entries[] | select(.key | contains("sriov"))'

# Inside a pod, verify the VF interface
kubectl exec -it gpu-training -- ip link show
# Should show net1 (or similar) as the SR-IOV VF interface

kubectl exec -it gpu-training -- ibv_devinfo
# Should show the VF with RDMA capability

VF Partitioning Strategies

Dedicated VFs per Training Job

Assign one VF per training pod for maximum isolation:

resources:
  limits:
    nvidia.com/sriov_rdma_vf: 1

Multiple VFs for Multi-Rail

For maximum bandwidth, assign multiple VFs (one per physical port):

resources:
  limits:
    nvidia.com/sriov_rdma_vf_port0: 1
    nvidia.com/sriov_rdma_vf_port1: 1

VF Pool Sizing

Calculate VF requirements:

• Number of GPU pods per node x VFs per pod = minimum VFs needed
• Add 10-20% buffer for scheduling flexibility
• Do not exceed the NIC’s maximum VF count

Troubleshooting

VFs Not Created

# Check SR-IOV operator logs
kubectl logs -n nvidia-network-operator -l app=sriov-network-config-daemon

# Verify IOMMU is enabled
dmesg | grep -i iommu

# Check if SR-IOV is enabled in the NIC firmware
mstconfig -d /dev/mst/mt4125_pciconf0 query | grep SRIOV_EN

Pod Cannot Get VF

# Check available VF resources
kubectl describe node gpu-node-1 | grep sriov

# If 0 allocatable, check:
# 1. SriovNetworkNodePolicy matches node labels
# 2. NIC selector matches actual hardware
# 3. Driver pods are running

Automating with Ansible

Deploy SR-IOV configuration across multiple clusters with Ansible:

---
- name: Configure SR-IOV on GPU Kubernetes cluster
  hosts: localhost
  vars:
    num_vfs: 8
    nic_vendor: "15b3"
  tasks:
    - name: Apply NicClusterPolicy
      kubernetes.core.k8s:
        state: present
        definition:
          apiVersion: mellanox.com/v1alpha1
          kind: NicClusterPolicy
          metadata:
            name: nic-cluster-policy
          spec:
            sriovDevicePlugin:
              image: sriov-network-device-plugin
              repository: ghcr.io/k8snetworkplumbingwg
              version: v3.7.0

    - name: Create SriovNetworkNodePolicy
      kubernetes.core.k8s:
        state: present
        src: manifests/sriov-node-policy.yaml

Final Thoughts

SR-IOV VFs give your GPU pods dedicated, hardware-accelerated network interfaces with near-bare-metal performance. For distributed AI training where NCCL communication is the bottleneck, the combination of SR-IOV VFs with RDMA and GPUDirect delivers the highest possible inter-node bandwidth. The overhead is worth it for any serious multi-node GPU workload.
