Distributed vLLM on Run:ai: Deploying Mistral

The Setup: Mistral 119B on 2 GPUs

Deploying a 119-billion parameter model for production inference requires splitting the model across multiple GPUs. This is a real-world deployment of Mistral-Small-4-119B (a multimodal Pixtral architecture) using Run:ai distributed inference, vLLM 0.18.0, and NCCL 2.27.5 on an enterprise Kubernetes cluster.

The infrastructure:

• 2x GPUs connected via NVLink at 123.6 GB/s
• Mellanox ConnectX (mlx5) at 400 Gbps RoCE for inter-node NCCL communication
• GPU Direct RDMA enabled for zero-copy GPU-to-network transfers
• OpenShift with Multus CNI for secondary network interfaces
• Air-gapped deployment — no internet access, model loaded from persistent volume
• 96 CPU cores available, non-root execution (UID/GID 2000)

The Run:ai CLI Command

Here is the exact command to submit a distributed inference workload on Run:ai:

runai inference distributed submit mistral-119b-dist-nccl \
  -p my-ai-project \
  -i registry.internal.example.com/ai-platform/vllm-openai:latest \
  --existing-pvc claimname=my-ai-project,path=/data \
  --workers 2 \
  -g 2 \
  --serving-port container=8000,authorization-type=authenticatedUsers \
  --environment-variable TRANSFORMERS_OFFLINE=1 \
  --environment-variable HF_HUB_OFFLINE=1 \
  --environment-variable NCCL_DEBUG=INFO \
  --environment-variable NCCL_DEBUG_SUBSYS=ALL \
  --environment-variable NCCL_SOCKET_IFNAME=net1 \
  --extended-resource "openshift.io/mellanoxnics=1" \
  --annotation "k8s.v1.cni.cncf.io/networks=secondary-network" \
  --run-as-uid 2000 \
  --run-as-gid 2000 \
  --run-as-non-root \
  --preemptibility preemptible \
  -- --model /data/input/Models/Mistral-Small-4-119B \
  --served-model-name mistral4 \
  --tensor-parallel-size 2 \
  --port 8000

Let me break down every flag.

Run:ai Distributed Inference Flags

NCCL Environment Variables

For InfiniBand-enabled clusters, replace with:

--environment-variable NCCL_NET=IB \
--environment-variable NCCL_IB_HCA=mlx5_0:1 \
--environment-variable NCCL_SOCKET_IFNAME=eth1

vLLM Arguments (After --)

Air-Gapped Model Loading

Two critical environment variables ensure no internet access is attempted:

TRANSFORMERS_OFFLINE=1
HF_HUB_OFFLINE=1

The model weights (in consolidated*.safetensors format) are pre-downloaded to the PVC at /data/input/Models/Mistral-Small-4-119B. vLLM infers torch.bfloat16 dtype from the safetensors files and automatically applies fp8 quantization for efficient inference.

What the NCCL Logs Tell You

The NCCL debug output is a goldmine of information about your GPU topology, interconnect performance, and communication patterns. Here is how to read it.

GPU Topology

=== System : maxBw 123.6 totalBw 123.6 ===
CPU/0-1 (1/1/3)
+ PCI[48.0] - PCI/0-115000
              + PCI[48.0] - GPU/0-118000 (0)
                            + NVL[123.6] - GPU/0-1b3000
              + PCI[48.0] - NIC/0-119000
+ PCI[48.0] - PCI/0-1b0000
              + PCI[48.0] - GPU/0-1b3000 (1)
                            + NVL[123.6] - GPU/0-118000

What this tells you:

• 2 GPUs (bus IDs 118000 and 1b3000) connected via NVLink at 123.6 GB/s
• 1 Mellanox NIC (bus ID 119000) on the same PCI tree as GPU 0
• PCI bandwidth: 48.0 GB/s per link
• Both GPUs sit under the same CPU socket (CPU/0-1)

GPU Distance Matrix

GPU/0-118000 : GPU/0-118000 (0/5000.0/LOC) GPU/0-1b3000 (1/123.6/NVL) CPU/0-1 (2/48.0/PHB)
GPU/0-1b3000 : GPU/0-118000 (1/123.6/NVL) GPU/0-1b3000 (0/5000.0/LOC) CPU/0-1 (2/48.0/PHB)

• LOC (distance 0): GPU to itself — 5 TB/s (local memory bandwidth)
• NVL (distance 1): GPU-to-GPU via NVLink — 123.6 GB/s
• PHB (distance 2): GPU to CPU via PCI Host Bridge — 48.0 GB/s

NVLink at 123.6 GB/s means tensor parallelism is viable — the AllReduce operations that synchronize activations across GPUs will not bottleneck inference.

Network Detection

NET/IB: [0] mlx5_130:uverbs132:1/RoCE provider=Mlx5 speed=400000
NET/IB : Using [0]mlx5_130:1/RoCE [RO]; OOB net1:10.x.x.x
GPU Direct RDMA Enabled for HCA 0 'mlx5_130'
GPU Direct RDMA Enabled for GPU 0 / HCA 0 (distance 4 <= 5), read 0 mode Default
GPU Direct RDMA Enabled for GPU 1 / HCA 0 (distance 4 <= 5), read 0 mode Default

Key takeaways:

• mlx5_130 — Mellanox ConnectX adapter at 400 Gbps RoCE
• GPU Direct RDMA enabled for both GPUs — data flows directly from GPU memory to the NIC without CPU involvement
• Distance 4 from GPU to NIC (PCIe hops) — within the threshold of 5 for RDMA
• Bootstrap on net1 — the Multus secondary interface handles NCCL coordination

Communication Channels

8 coll channels, 8 collnet channels, 0 nvls channels, 8 p2p channels per peer
Pattern 4: nChannels 4, bw 30.0/30.0, type NVL/PIX
Pattern 1: nChannels 4, bw 60.0/60.0, type NVL/PIX

NCCL selected 8 communication channels with:

• AllReduce bandwidth: 60 GB/s (Pattern 1, Ring algorithm)
• AllGather/ReduceScatter: 120-240 GB/s (Ring, Simple protocol)
• P2P transport: P2P/CUMEM (CUDA memory direct transfers via NVLink)

Ring and Tree Topology

Ring 00 : 0 -> 1 -> 0
Ring 01 : 0 -> 1 -> 0
...
Trees [0] 1/-1/-1->0->-1  [2] -1/-1/-1->0->1

With only 2 GPUs, the ring is trivial (0→1→0). The tree topology alternates roots between GPU 0 and GPU 1 across the 8 channels for balanced bandwidth.

vLLM Engine Configuration

model: Mistral-Small-4-119B
architecture: PixtralForConditionalGeneration
dtype: torch.bfloat16
quantization: fp8
max_seq_len: 1048576
tensor_parallel_size: 2
pipeline_parallel_size: 1
chunked_prefill: enabled (max_num_batched_tokens=8192)
enable_prefix_caching: True

Notable details:

• Pixtral architecture — this is a multimodal model (vision + language), not just text
• FP8 quantization applied automatically — reduces memory footprint by ~50% vs BF16
• 1M token context window — Mistral’s sliding window attention architecture supports extreme context lengths
• Chunked prefill enabled — batches up to 8192 tokens per chunk to avoid blocking decode operations
• Prefix caching — repeated prompts skip recomputation of cached KV states

vLLM 0.18.0 Deprecation Warning

WARNING: With `vllm serve`, you should provide the model as a
positional argument instead of via the `--model` option.
The `--model` option will be removed in v0.13.

Starting with vLLM 0.13+, use vllm serve /data/input/Models/Mistral-Small-4-119B instead of --model. Run:ai’s distributed inference passes arguments after -- directly to the container entrypoint.

NCCL Init Performance

Init timings - ncclCommInitRank: rank 0 nranks 2 total 0.33
  (kernels 0.19, alloc 0.11, bootstrap 0.00, topo 0.01,
   graphs 0.00, connections 0.01)

NCCL initialization completed in 0.33 seconds for the first communicator — this is fast, indicating the NVLink topology was detected cleanly. The second communicator (for vLLM’s internal pipeline) initialized in 0.05 seconds using cached topology.

OpenShift and Multus Integration

Secondary Network for NCCL

The annotation k8s.v1.cni.cncf.io/networks=secondary-network tells Multus to attach a second network interface (net1) to each pod. NCCL uses this interface for:

• Bootstrap: Initial peer discovery and rank assignment
• Inter-node communication: If workers span multiple nodes, NCCL AllReduce goes over this 400G RoCE fabric

Mellanox NIC as Extended Resource

--extended-resource "openshift.io/mellanoxnics=1"

This requests one Mellanox NIC from the SR-IOV device plugin. Each pod gets a dedicated VF (Virtual Function) for line-rate network access without sharing with other tenants.

Non-Root Execution

--run-as-uid 2000 --run-as-gid 2000 --run-as-non-root

Required by OpenShift’s restricted SCC. The vLLM container must be built to run as non-root — model files on the PVC must be readable by UID 2000.

Production Tuning Checklist

Based on the NCCL logs, here is what to verify for production:

Confirm NVLink Is Used (Not PCIe Fallback)

# In NCCL logs, look for:
# NVL[123.6] — good, NVLink active
# PIX or PHB — fallback to PCIe, investigate

Verify GPU Direct RDMA

# In NCCL logs:
# "GPU Direct RDMA Enabled for GPU X / HCA Y" — good
# "GPU Direct RDMA Disabled" — check NVIDIA peer memory module

Check for Missing libnccl-net.so

NET/Plugin: Could not find: libnccl-net.so.

This means NCCL is using its built-in IB verbs path instead of an optimized plugin. For most deployments this is fine, but for maximum multi-node performance, install the NCCL network plugin matching your NCCL version.

Monitor NCCL AllReduce Performance

# Expected bandwidth for 2 GPUs on NVLink:
# Ring AllReduce: ~60 GB/s
# If significantly lower, check:
# - NCCL_SOCKET_IFNAME pointing to correct interface
# - PFC enabled on the RoCE fabric
# - GPU affinity settings

Torch Thread Count

WARNING: Reducing Torch parallelism from 96 threads to 1
to avoid unnecessary CPU contention.

NCCL automatically reduces PyTorch threads from 96 (matching CPU cores) to 1 for the executor to avoid lock contention. This is correct behavior — set OMP_NUM_THREADS only if you need specific threading.

Architecture Decision: When to Use This Pattern

This deployment pattern — Run:ai distributed inference with vLLM and tensor parallelism — is the right choice when:

• Model exceeds single-GPU memory — Mistral 119B in BF16 needs ~238 GB; even with FP8, it needs ~119 GB, exceeding a single 80 GB GPU
• Low-latency inference required — tensor parallelism splits each forward pass across GPUs, reducing latency (unlike pipeline parallelism which adds latency per stage)
• Air-gapped enterprise environment — no cloud API calls, all inference on-premise
• Multi-tenant GPU cluster — Run:ai handles scheduling, quotas, and preemption across teams

For models that fit in a single GPU (under ~70B parameters with FP8), skip distributed inference and use a standard runai inference submit — the NCCL overhead is not worth it.
