The moment your RISC-V system has more than one hart, a subtle question appears: when one core writes memory, when exactly does another core see it? The answer is governed by the memory model, and RISC-V’s is called RVWMO. Get it right and you can write fast, correct lock-free code; get it wrong and you get the worst kind of bug — the intermittent one. Here is what every systems programmer should know.
Why Memory Models Exist
On a single core, instructions appear to run in order. Across multiple cores with caches and store buffers, the hardware reorders memory operations for speed — a store might sit in a buffer while later loads complete. A memory model is the contract that says which reorderings are allowed and how software can restrain them. Every modern ISA has one; RISC-V’s is RVWMO.
RVWMO: Weak by Design
RVWMO (RISC-V Weak Memory Ordering) is a relaxed model. By default, the hardware may reorder independent loads and stores from a single hart as observed by others. This is deliberate: weak ordering lets designers build faster, more scalable multicore and server chips without the synchronization tax of a strongly-ordered model like x86’s TSO.
The trade-off: you must insert ordering where it matters. Fortunately, this is rare in everyday code — compilers, std::atomic, and kernel primitives handle it. But if you write lock-free data structures, drivers, or synchronization primitives, RVWMO is essential knowledge.
There is also a stronger optional extension, Ztso, providing total-store-order semantics for easier porting of code written against x86 — useful for software migration.
Fences: Enforcing Order
The fence instruction is how you restrain reordering. It orders memory operations before it against those after it, with predecessor/successor sets of reads (R) and writes (W):
fence rw, rw # full barrier: all earlier R/W before all later R/W
fence w, w # order earlier writes before later writes
fence r, r # order earlier reads before later reads
fence.i # instruction-fetch fence (after writing code, e.g. JIT)A classic use: producer writes data, then a flag. Without a fence a consumer might see the flag set before the data lands. fence w, w between the two writes (and fence r, r on the reader) prevents that.
The A Extension: Atomics
The A (Atomic) extension — part of the G/RV64GC baseline — provides two complementary mechanisms.
AMO: Atomic Memory Operations
A single instruction does an atomic read-modify-write:
amoadd.w a0, a1, (a2) # atomically: a0 = *a2; *a2 = a0 + a1
amoswap.w a0, a1, (a2) # atomically swap
amoor.w / amoand.w / amomax.w ...AMOs also carry optional .aq (acquire) and .rl (release) ordering bits, so you can express acquire/release semantics directly on the atomic — exactly what C++ memory_order_acquire/release map to.
LR/SC: Load-Reserved / Store-Conditional
For arbitrary atomic sequences (like compare-and-swap), RISC-V uses a reservation pair:
retry:
lr.w t0, (a0) # load-reserved: read and reserve the address
bne t0, a1, fail # not the expected value? bail
sc.w t2, a2, (a0) # store-conditional: succeeds only if reservation intact
bnez t2, retry # t2 != 0 => SC failed (someone else wrote), retry
fail:sc succeeds only if no other hart wrote the reserved address since the lr. This is the foundation for compare-and-swap and most lock-free algorithms. Keep the LR/SC body tiny — long or memory-touching sequences can cause the reservation to be lost and loop forever.
Acquire and Release in Practice
Most concurrency reduces to two patterns:
- Acquire (e.g. taking a lock): no later memory access may move before it.
- Release (e.g. dropping a lock): no earlier access may move after it.
RISC-V expresses these with the .aq/.rl bits on atomics, or with explicit fences. If you use a high-level language, std::atomic (C++), atomic (Rust), or kernel macros generate the correct instructions for you — you rarely hand-write them, but understanding the mapping helps you reason about correctness.
Why This Matters Beyond Theory
Memory-model bugs are notoriously hard: they appear only under specific timing, on specific microarchitectures, and vanish under a debugger. RVWMO’s value is that it is formally specified — it was developed with rigorous formal methods and tooling (like the herd/litmus test suites), so hardware and software can be checked against a precise definition rather than folklore. That formality is a genuine strength of the RISC-V specification.
The Bottom Line
RISC-V uses RVWMO, a weak memory model that trades default ordering guarantees for performance and scalability. You restore the ordering you need with fence instructions and the A extension’s atomics — AMOs for single-instruction read-modify-write and LR/SC for lock-free compare-and-swap, both with optional acquire/release semantics. For most code your compiler and standard library handle this; for systems and concurrency work, RVWMO is one of the most important parts of the ISA to understand.
