RAG Pipeline on Kubernetes: Production Architecture Guide

Production RAG Architecture

┌─────────────────────────────────────────────────────────┐
│                    Kubernetes Cluster                    │
│                                                         │
│  ┌──────────┐    ┌──────────┐    ┌──────────────────┐  │
│  │  Ingress │───▶│ API      │───▶│ Orchestrator     │  │
│  │  (Kong)  │    │ Gateway  │    │ (Argo Workflows) │  │
│  └──────────┘    └──────────┘    └────────┬─────────┘  │
│                                           │             │
│         ┌─────────────────────────────────┼──────┐      │
│         │                                 │      │      │
│         ▼                                 ▼      ▼      │
│  ┌──────────────┐  ┌──────────────┐  ┌────────────┐   │
│  │  Embedding   │  │   Vector DB  │  │    LLM     │   │
│  │  Service     │  │   (Qdrant)   │  │  (vLLM)    │   │
│  │  (TEI)       │  │              │  │            │   │
│  └──────────────┘  └──────────────┘  └────────────┘   │
│                                                         │
│  ┌──────────────┐  ┌──────────────┐  ┌────────────┐   │
│  │  Document    │  │  Reranker    │  │   Redis    │   │
│  │  Processor   │  │  (cross-enc) │  │  (cache)   │   │
│  └──────────────┘  └──────────────┘  └────────────┘   │
└─────────────────────────────────────────────────────────┘

Component Breakdown

1. Document Ingestion Pipeline

apiVersion: argoproj.io/v1alpha1
kind: Workflow
metadata:
  name: document-ingestion
spec:
  entrypoint: ingest
  templates:
    - name: ingest
      steps:
        - - name: extract
            template: extract-text
        - - name: chunk
            template: chunk-documents
        - - name: embed
            template: generate-embeddings
        - - name: store
            template: store-vectors

    - name: extract-text
      container:
        image: unstructured-io/unstructured:latest
        args: ["--input-dir", "/data/raw", "--output-dir", "/data/extracted"]

    - name: chunk-documents
      container:
        image: myregistry/chunker:latest
        env:
          - name: CHUNK_SIZE
            value: "512"
          - name: CHUNK_OVERLAP
            value: "50"
          - name: STRATEGY
            value: "semantic"  # semantic > fixed-size > recursive

    - name: generate-embeddings
      container:
        image: ghcr.io/huggingface/text-embeddings-inference:latest
        resources:
          limits:
            nvidia.com/gpu: "1"

    - name: store-vectors
      container:
        image: myregistry/vector-store:latest
        env:
          - name: QDRANT_URL
            value: "http://qdrant.vector-db:6333"

2. Embedding Service (TEI)

HuggingFace Text Embeddings Inference — optimized for throughput:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: embedding-service
spec:
  replicas: 2
  template:
    spec:
      containers:
        - name: tei
          image: ghcr.io/huggingface/text-embeddings-inference:1.5
          args:
            - "--model-id"
            - "BAAI/bge-large-en-v1.5"
            - "--max-batch-tokens"
            - "16384"
            - "--max-concurrent-requests"
            - "512"
          ports:
            - containerPort: 80
          resources:
            limits:
              nvidia.com/gpu: "1"
            requests:
              memory: "4Gi"

3. Retrieval + Reranking Service

# retrieval_service.py
from fastapi import FastAPI
from qdrant_client import QdrantClient
from sentence_transformers import CrossEncoder

app = FastAPI()
qdrant = QdrantClient(host="qdrant.vector-db.svc", port=6333)
reranker = CrossEncoder("cross-encoder/ms-marco-MiniLM-L-12-v2")

@app.post("/retrieve")
async def retrieve(query: str, top_k: int = 10, rerank_top_k: int = 5):
    # Step 1: Embed query
    query_embedding = await embed(query)

    # Step 2: Vector search (fast, approximate)
    results = qdrant.search(
        collection_name="documents",
        query_vector=query_embedding,
        limit=top_k,
        score_threshold=0.7,
    )

    # Step 3: Rerank (precise, cross-encoder)
    passages = [r.payload["text"] for r in results]
    scores = reranker.predict([(query, p) for p in passages])

    # Step 4: Return top reranked results
    ranked = sorted(zip(results, scores), key=lambda x: x[1], reverse=True)
    return [{"text": r.payload["text"], "score": s} for r, s in ranked[:rerank_top_k]]

4. Generation with Retrieved Context

@app.post("/generate")
async def generate(query: str):
    # Retrieve relevant context
    context_docs = await retrieve(query, top_k=10, rerank_top_k=5)
    context = "\n\n".join([d["text"] for d in context_docs])

    # Generate with LLM
    response = await vllm_client.chat.completions.create(
        model="meta-llama/Llama-3.1-70B-Instruct",
        messages=[
            {"role": "system", "content": f"Answer based on this context:\n{context}"},
            {"role": "user", "content": query}
        ],
        temperature=0.1,
        max_tokens=1024,
    )
    return {"answer": response.choices[0].message.content, "sources": context_docs}

Chunking Strategies

Semantic Chunking Example

from langchain.text_splitter import SemanticChunker
from langchain.embeddings import HuggingFaceEmbeddings

embeddings = HuggingFaceEmbeddings(model_name="BAAI/bge-small-en-v1.5")
splitter = SemanticChunker(
    embeddings,
    breakpoint_threshold_type="percentile",
    breakpoint_threshold_amount=95,
)

chunks = splitter.split_text(document_text)

Caching Layer

Redis caches both embeddings and LLM responses:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: redis-cache
spec:
  template:
    spec:
      containers:
        - name: redis
          image: redis:7-alpine
          args: ["--maxmemory", "4gb", "--maxmemory-policy", "allkeys-lru"]
          resources:
            limits:
              memory: "5Gi"

import hashlib, redis, json

cache = redis.Redis(host="redis-cache.ai-inference.svc")

def cached_retrieve(query: str):
    key = f"rag:{hashlib.md5(query.encode()).hexdigest()}"
    cached = cache.get(key)
    if cached:
        return json.loads(cached)
    result = retrieve(query)
    cache.setex(key, 3600, json.dumps(result))  # 1 hour TTL
    return result

Scaling Considerations

Production Checklist

• Document versioning (re-embed on update, not append)
• Metadata filtering (date, source, category)
• Hybrid search (vector + BM25 keyword)
• Citation extraction (return source documents)
• Guardrails (content filtering, hallucination detection)
• A/B testing (chunking strategies, embedding models)
• Monitoring (retrieval precision, generation quality)
• Cost tracking (embedding + search + generation per query)
