RAG Architecture for Enterprise Knowledge

Retrieval-Augmented Generation (RAG) bridges the gap between general-purpose LLMs and your organization’s proprietary knowledge. Instead of fine-tuning a model on your data (expensive, slow, goes stale), RAG retrieves relevant context at query time and feeds it to the LLM.

How RAG Works

User Query → Embedding → Vector Search → Top-K Documents → LLM + Context → Answer

1. User asks a question: “What is our SLA for tier-1 customers?”
2. Query embedding: Convert the question to a vector (1536 dimensions with OpenAI, 768 with open models)
3. Vector search: Find the most similar document chunks in the vector database
4. Context assembly: Combine the top-K results into a prompt
5. LLM generation: The model answers using the retrieved context, not its training data

Architecture Components

Document Ingestion Pipeline

Raw Documents → Chunking → Embedding → Vector Store
     ↓              ↓           ↓           ↓
  PDF, Docs,    Split into   Convert to   Store in
  Confluence,   overlapping  vectors via  Qdrant,
  Slack, Git    chunks       embedding    Weaviate,
                (512-1024    model        Milvus,
                 tokens)                  pgvector

Chunking Strategy

The most important decision in RAG. Poor chunking = poor retrieval = poor answers.

# Bad: Fixed-size chunks break mid-sentence
chunks = [text[i:i+500] for i in range(0, len(text), 500)]

# Better: Semantic chunking with overlap
from langchain.text_splitter import RecursiveCharacterTextSplitter

splitter = RecursiveCharacterTextSplitter(
    chunk_size=512,
    chunk_overlap=50,
    separators=["

", "
", ". ", " "]
)
chunks = splitter.split_text(text)

# Best: Document-structure-aware chunking
# Split on headings, preserve sections, keep tables intact

Vector Database Selection

Embedding Models

For enterprise use, self-hosted models (BGE, E5) avoid sending data to external APIs.

Advanced RAG Patterns

Hybrid Search

Combine vector search with keyword search for better retrieval:

# Vector search finds semantically similar documents
vector_results = vector_db.search(query_embedding, top_k=10)

# BM25 keyword search finds exact term matches
keyword_results = bm25_index.search(query_text, top_k=10)

# Reciprocal Rank Fusion combines both
final_results = reciprocal_rank_fusion(vector_results, keyword_results)

Multi-Query RAG

Generate multiple search queries from a single user question:

# User asks: "How does our authentication work?"
# Generate search queries:
queries = [
    "authentication system architecture",
    "login flow and OAuth implementation",
    "user session management",
    "SSO and identity provider integration"
]
# Search with all queries, deduplicate results

Parent Document Retrieval

Store small chunks for precise retrieval, but return the full parent document for context:

# Index small chunks (256 tokens) for precise matching
# But return the parent section (2000 tokens) for full context
# This gives the LLM enough surrounding context to answer well

Production Considerations

1. Freshness: Schedule re-ingestion for frequently updated sources (Confluence, Git)
2. Access control: Filter results based on user permissions — do not let RAG bypass document ACLs
3. Evaluation: Measure retrieval quality (recall@k) and answer quality (faithfulness, relevance)
4. Caching: Cache common query embeddings and their results
5. Monitoring: Track retrieval latency, cache hit rate, LLM token usage, and answer quality scores

Cost Estimation

Monthly RAG cost for 10K documents, 1K queries/day:

Embedding (one-time): 10K docs × avg 2K tokens = 20M tokens → $2.60
Vector DB: Qdrant cloud small instance → $25/month
LLM inference: 1K queries × 2K context tokens × 30 days = 60M tokens → ~$90/month
Re-embedding (weekly): $0.65/week → $2.60/month

Total: ~$120/month for 30K queries
