OpAMP: Manage OpenTelemetry Collector Fleets Safely

OpAMP, the Open Agent Management Protocol, is how you stop SSH-ing into hosts to change an OpenTelemetry Collector config. With more than a handful of Collectors, the hard part is knowing what each one runs, whether it’s healthy, and getting a change such as “stop shipping that email attribute” onto all of them without taking the pipeline down. This post shows how OpAMP does that for a Collector fleet, with a lab I ran locally and an OTTL redaction change pushed over the wire.

In February I went to the SRE NL meetup at Elastic in Amsterdam. Near the end of the OpenTelemetry talk, a “To infinity and beyond” slide listed Baggage, OTTL and OpAMP as the next things to learn, and OpAMP is described there as “remote management of large fleets of data collection Agents”. I wrote the evening up in my SRE NL at Elastic recap.

In the audience for the OpenTelemetry talk at SRE NL at Elastic Amsterdam.

Versions I verified against: OpAMP specification (Status: Beta, opamp-spec v0.20.0), opamp-go v0.25.0, OpenTelemetry Collector Contrib v0.162.0 and the OpAMP Supervisor v0.162.0. I ran everything below on macOS (arm64) with the release binaries.

What OpAMP is, and what it isn’t

OpAMP is a network protocol. The specification says it lets agents report their status to a server, receive configuration from it, and receive agent package updates. It’s vendor-agnostic, so one server can manage a mixed fleet.

The pieces:

• Server: holds the desired state and the fleet inventory. Many clients connect to one server.
• Client: speaks OpAMP on behalf of an agent. The spec doesn’t require the client to live inside the agent. It can be a plugin, a sidecar or a separate Supervisor process.
• Transport: WebSocket or plain HTTP (polling). Servers should accept both. The default path is /v1/opamp and the default port is 4320.
• Identity: each agent has an instance_uid. The extension’s docs ask for a UUIDv7.

The specification as a whole is marked Beta. Some fields, such as available components, custom messages and heartbeats, are still marked Development.

The slide at SRE NL at Elastic: OpAMP as “remote management of large fleets of data collection Agents”, next to Baggage and OTTL.

What it isn’t: a rollout engine. OpAMP carries the config, the status and the hashes. Deciding which Collectors get which config, and when, is your server’s job.

The capabilities that matter

During the first message exchange, the agent and server each send a capabilities bit field. A server must not use a capability the agent didn’t announce. These are the ones that matter for running a Collector fleet:

OpAMP extension vs OpAMP Supervisor

Collector Contrib ships two components, and the difference is the most important thing to understand.

The OpAMP extension (opamp, in extension/opampextension) is alpha and ships in the contrib and k8s distributions. It runs inside the Collector and reports: agent description, effective config, health and available components. It can also accept a restart command behind the extension.opampextension.RemoteRestarts feature gate. It doesn’t accept remote config. When I connected a Collector with only the extension, it announced ReportsStatus|ReportsEffectiveConfig|ReportsHealth|ReportsAvailableComponents and nothing else.

The OpAMP Supervisor (cmd/opampsupervisor) is a separate binary, also alpha, published under release tags that start with cmd/opampsupervisor. It starts the Collector as a child process, connects to your OpAMP server, receives remote config, merges it with local files, writes the result and restarts the Collector. It configures the extension to connect back to a local OpAMP endpoint inside the Supervisor. Its README lists AcceptsRemoteConfig, effective config, own telemetry, connection settings, restart and available components as implemented. ReportsHealth works with caveats. Package handling and Collector binary updates are still linked to open issues.

My take: use the extension alone if you want an inventory and nothing pushed into production. Use the Supervisor if the server is meant to change configs.

A local lab: example server, Supervisor and a Collector

The opamp-go repository includes an example server with a small web UI. It’s a reference implementation, not a product.

git clone --depth 1 --branch v0.25.0 https://github.com/open-telemetry/opamp-go.git
cd opamp-go/internal/examples/server
go run .
# OpAMP on 0.0.0.0:4320/v1/opamp with TLS, UI on http://localhost:4321

The server uses demo certificates from internal/examples/certs, and its listener binds to every interface. Keep it on a laptop.

Get the Collector and the Supervisor (swap in your OS and architecture):

V=0.162.0
curl -fLO "https://github.com/open-telemetry/opentelemetry-collector-releases/releases/download/v${V}/otelcol-contrib_${V}_darwin_arm64.tar.gz"
tar xzf "otelcol-contrib_${V}_darwin_arm64.tar.gz" otelcol-contrib
curl -fL -o opampsupervisor "https://github.com/open-telemetry/opentelemetry-collector-releases/releases/download/cmd%2Fopampsupervisor%2Fv${V}/opampsupervisor_${V}_darwin_arm64"
chmod +x opampsupervisor

A local base config, base.yaml, that the Collector always gets:

receivers:
  otlp:
    protocols:
      http:
        endpoint: 127.0.0.1:4318

exporters:
  debug:
    verbosity: detailed

service:
  pipelines:
    logs:
      receivers: [otlp]
      exporters: [debug]

And supervisor.yaml:

server:
  endpoint: wss://127.0.0.1:4320/v1/opamp
  tls:
    ca_file: ./opamp-go/internal/examples/certs/certs/ca.cert.pem

capabilities:
  accepts_remote_config: true      # default false: remote config is opt-in
  reports_effective_config: true
  reports_health: true
  reports_own_metrics: false       # default true; off here, nothing to receive it

agent:
  executable: ./otelcol-contrib
  config_files:
    - ./base.yaml
  validate_config: true            # run `otelcol validate` before applying (default false)
  automatic_config_rollback: true  # fall back to the last working config (default false)
  passthrough_logs: true           # Collector logs in the Supervisor log
  description:
    non_identifying_attributes:
      fleet.ring: canary

storage:
  directory: ./supervisor-state    # default /var/lib/otelcol/supervisor

healthcheck:
  endpoint: 127.0.0.1:13140        # GET /health; disabled unless set

Run ./opampsupervisor --config=supervisor.yaml. The Supervisor logged Connected to the OpAMP server., started the Collector, and the server saw the agent with AcceptsRemoteConfig in its capabilities, fleet.ring: canary in its description and RemoteConfigStatus=APPLIED. The agent then appears in the UI on port 4321.

Pushing an OTTL redaction change

Before any change, I sent an OTLP/HTTP log record with an email in the body and the attributes user.email, http.request.header.authorization and db.password. The debug exporter printed all of it, plus a DEBUG record. That’s the leak we want to fix fleet-wide.

The remote config only contains what changes. The Supervisor merges it on top of base.yaml:

processors:
  filter/drop-debug:
    error_mode: ignore
    log_conditions:
      - log.severity_number < SEVERITY_NUMBER_INFO

  transform/redact-pii:
    error_mode: ignore
    log_statements:
      - delete_key(log.attributes, "http.request.header.authorization")
      - delete_matching_keys(log.attributes, "(?i).*(password|secret|token).*")
      - set(log.attributes["user.email"], SHA256(log.attributes["user.email"])) where log.attributes["user.email"] != nil
      - replace_pattern(log.body, "[A-Za-z0-9._%+-]+@[A-Za-z0-9.-]+\\.[A-Za-z]{2,}", "[email]")
      - replace_pattern(log.body, "\\b(?:\\d[ -]?){13,16}\\b", "[card]")

service:
  pipelines:
    logs:
      processors: [filter/drop-debug, transform/redact-pii]

Line by line:

• filter drops what matches. Any log below INFO is removed before the transform runs. The filter processor’s logs signal is alpha in v0.162.0.
• delete_key and delete_matching_keys remove the auth header and anything whose key looks like a credential. The (?i) makes the regex case-insensitive.
• SHA256 replaces the email with its hash, so you can still count unique users without storing the address.
• replace_pattern on log.body masks emails and card-like numbers inside free text. Attribute rules don’t help when the PII is in the message string.
• error_mode: ignore logs a failed statement and moves on. The transform processor’s README recommends it, so one bad record doesn’t drop the batch.

Before pushing, validate the merged result exactly as the Supervisor will build it:

./otelcol-contrib validate --config=base.yaml --config=remote-redact.yaml

Then paste it into the agent’s page in the example UI and save. The server logged APPLYING, then APPLIED. Sending the same records again gave:

Body: Str(payment ok for [email] card [card])
-> user.email: Str(86e0b9e56c17cc4d12387e1949b85053fbe73bc3ce5a1188713a9d300cc6133d)
-> http.route: Str(/pay)

The authorization header and password were gone, and the DEBUG record never reached the exporter.

Contrib also has a dedicated redaction processor; the OTTL version is easier to roll out as a small diff.

Rolling out config changes safely across a fleet

This is where fleets break. A safe rollout uses settings that are already in the Supervisor:

1. Validate on the agent. With validate_config: true, the Supervisor runs the Collector’s validate against the merged config before switching. I pushed a config that called a non-existent delete_keys function. The Supervisor logged New configuration failed validation, keeping previous config, reported FAILED with the validation error to the server, and redaction kept working on the old config.
2. Roll back on a bad start. automatic_config_rollback: true caches the last working remote config and restores it if a new one stops the Collector from starting. Both settings are off by default. Turn them on.
3. Stage by ring. Put fleet.ring (or region, cluster, team) in agent::description::non_identifying_attributes, and have your server offer a new config to canaries first. Promote only when they report APPLIED, healthy, and their effective config hash matches what you sent.
4. Survive an outage. startup_fallback_configs gives a Collector a known-good, standalone config when it starts with no persisted state and can’t reach the server.
5. Watch the Collectors, not just the server. With reports_own_metrics, the server can point each Collector’s own metrics at an OTLP endpoint. For an OTTL change, compare otelcol_processor_incoming_items and otelcol_processor_outgoing_items for the filter before and after.

The OpenTelemetry talk’s live demo in Elastic Observability, on both screens at SRE NL.

My take: a config that passes validate can still drop everything. The canary ring and a throughput comparison catch that; the validator doesn’t.

Security: TLS, auth and what remote config may do

The spec is blunt: remote configuration and downloadable packages are “a significant security risk”, because a compromised server can make every agent do undesirable work. Treat your OpAMP server like your CI system.

• TLS everywhere. Both components use the Collector’s standard client TLS settings. Use ca_file (and cert_file/key_file for mTLS) instead of insecure_skip_verify, which only belongs in the README’s local example.
• Authenticate the client. The spec allows HTTP Basic or Bearer auth during the connection upgrade, and a server must answer 401 on failure. The extension takes headers or an auth extension ID per transport. For example, auth: bearertokenauth with a bearertokenauth extension (beta) reading a token filename. The Supervisor has server::headers. Its server::auth needs the alpha opampsupervisor.Extensions feature gate.
• Keep remote config opt-in. The spec recommends it, and the Supervisor defaults accepts_remote_config to false.
• Pin what remote config can’t override. Files in agent::config_files merge top to bottom, and $REMOTE_CONFIG goes last by default. The Supervisor’s design doc shows listing a compliance_config.yaml after $REMOTE_CONFIG, so your local redaction pipeline wins. That matters because the README lists “Sanitization or restriction of Collector config” as not implemented yet.
• Mind what you report. reports_raw_config on the extension can expose secrets written in config files, and it’s off by default. The Supervisor’s collector_crash_log_snippet_kib is off by default too, since Collector logs may contain sensitive data.
• Least privilege. The spec recommends not running the agent as root.

Pitfalls

• Expecting the extension to apply configs. It doesn’t. Remote config needs the Supervisor or your own OpAMP client.
• $ in pushed OTTL. The merged config goes through the Collector’s normal variable expansion, so a pushed "a$$b" arrived as a$b. Escape $ as $$, as the OTTL docs say for any Collector config.
• Deprecated reports_remote_config. In v0.162.0 the Supervisor logs an error if you set it. Remote config status is reported whenever accepts_remote_config is on.
• Lists replace, maps merge. My remote processors list was added to the local pipeline because the local one had none. Without the experimental confmap.enableMergeAppendOption gate, a list in a later file discards the earlier list instead of appending to it.
• False validation failures. The Supervisor warns that validation “may fail for valid configs if resources (e.g., ports) are temporarily unavailable”.
• Restart over SIGHUP. The extension’s restart command uses SIGHUP, which isn’t supported on Windows. A bad config then leaves the Collector down until something else restarts it.
• Hashing isn’t anonymising. An unsalted SHA-256 of an email can be reversed with a list of known addresses. Delete it if you don’t need it.

If the traces themselves are the problem, start with my OpenTelemetry trace quality checklist. Its gateway config is a good candidate to manage through OpAMP once it’s stable.
