OpenTelemetry on Kubernetes: Complete Observability Stack

What Is OpenTelemetry?

OpenTelemetry (OTel) is the CNCF standard for observability — collecting traces, metrics, and logs from applications. Vendor-neutral, supports 40+ backends.

The Three Pillars

┌─────────────────────────────────────────────────┐
│              Your Application                    │
│                                                 │
│  Traces ─────┐                                  │
│  Metrics ────┼──▶ OTel SDK ──▶ OTel Collector  │
│  Logs ───────┘                      │           │
└─────────────────────────────────────┼───────────┘
                                      │
                    ┌─────────────────┼────────────────┐
                    │                 │                │
                    ▼                 ▼                ▼
              ┌──────────┐    ┌────────────┐   ┌──────────┐
              │  Jaeger  │    │ Prometheus │   │   Loki   │
              │ (traces) │    │ (metrics)  │   │  (logs)  │
              └──────────┘    └────────────┘   └──────────┘

Collector Deployment

apiVersion: opentelemetry.io/v1beta1
kind: OpenTelemetryCollector
metadata:
  name: otel-collector
spec:
  mode: daemonset  # One per node (for logs) or deployment (for traces)
  config:
    receivers:
      otlp:
        protocols:
          grpc:
            endpoint: 0.0.0.0:4317
          http:
            endpoint: 0.0.0.0:4318
      prometheus:
        config:
          scrape_configs:
            - job_name: 'kubernetes-pods'
              kubernetes_sd_configs:
                - role: pod

    processors:
      batch:
        timeout: 5s
        send_batch_size: 1000
      memory_limiter:
        limit_mib: 512
      k8sattributes:
        extract:
          metadata:
            - k8s.pod.name
            - k8s.namespace.name
            - k8s.deployment.name

    exporters:
      otlp/jaeger:
        endpoint: jaeger-collector:4317
        tls:
          insecure: true
      prometheus:
        endpoint: 0.0.0.0:8889
      loki:
        endpoint: http://loki:3100/loki/api/v1/push

    service:
      pipelines:
        traces:
          receivers: [otlp]
          processors: [memory_limiter, k8sattributes, batch]
          exporters: [otlp/jaeger]
        metrics:
          receivers: [otlp, prometheus]
          processors: [memory_limiter, batch]
          exporters: [prometheus]
        logs:
          receivers: [otlp]
          processors: [memory_limiter, k8sattributes, batch]
          exporters: [loki]

Auto-Instrumentation (Zero Code)

apiVersion: opentelemetry.io/v1alpha1
kind: Instrumentation
metadata:
  name: auto-instrumentation
spec:
  exporter:
    endpoint: http://otel-collector:4317
  propagators:
    - tracecontext
    - baggage
  sampler:
    type: parentbased_traceidratio
    argument: "0.1"  # Sample 10% of traces
  python:
    image: ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-python:latest
  java:
    image: ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-java:latest
  nodejs:
    image: ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-nodejs:latest

Then annotate your pods:

metadata:
  annotations:
    instrumentation.opentelemetry.io/inject-python: "true"
    # or inject-java, inject-nodejs, inject-dotnet, inject-go

Zero application code changes. The operator injects the SDK automatically.

Sampling Strategies

For production: use tail-based sampling — keeps 100% of errors and slow requests, samples everything else.

Cost Comparison (Backends)

Self-hosted Tempo + MinIO is the most cost-effective for Kubernetes-native teams.
