OpenSSL Cheat Sheet 2026: Certificates and TLS Commands

A quick reference for OpenSSL — certificates, encryption, and TLS testing. Bookmark this page.

Certificate Operations

# Generate private key
openssl genrsa -out server.key 4096
openssl ecparam -genkey -name prime256v1 -out server-ec.key  # EC key

# Generate CSR (Certificate Signing Request)
openssl req -new -key server.key -out server.csr \
  -subj "/C=NL/ST=North Holland/L=Amsterdam/O=MyOrg/CN=example.com"

# Generate self-signed certificate
openssl req -x509 -newkey rsa:4096 -keyout key.pem -out cert.pem \
  -sha256 -days 365 -nodes \
  -subj "/CN=example.com"

# Generate self-signed with SAN
openssl req -x509 -newkey rsa:4096 -keyout key.pem -out cert.pem \
  -sha256 -days 365 -nodes \
  -subj "/CN=example.com" \
  -addext "subjectAltName=DNS:example.com,DNS:*.example.com,IP:10.0.0.1"

Inspect Certificates

# View certificate details
openssl x509 -in cert.pem -text -noout

# View specific fields
openssl x509 -in cert.pem -subject -noout
openssl x509 -in cert.pem -issuer -noout
openssl x509 -in cert.pem -dates -noout       # Validity dates
openssl x509 -in cert.pem -fingerprint -noout

# View CSR
openssl req -in server.csr -text -noout

# View private key
openssl rsa -in server.key -text -noout

# Check key matches certificate
openssl x509 -in cert.pem -modulus -noout | md5sum
openssl rsa -in key.pem -modulus -noout | md5sum
# If both MD5 hashes match, key and cert are paired

TLS Connection Testing

# Test TLS connection to a server
openssl s_client -connect example.com:443

# Show full certificate chain
openssl s_client -connect example.com:443 -showcerts

# Test specific TLS version
openssl s_client -connect example.com:443 -tls1_2
openssl s_client -connect example.com:443 -tls1_3

# Test specific cipher
openssl s_client -connect example.com:443 -cipher ECDHE-RSA-AES256-GCM-SHA384

# Check certificate expiration remotely
echo | openssl s_client -connect example.com:443 2>/dev/null | openssl x509 -dates -noout

# SNI (Server Name Indication)
openssl s_client -connect example.com:443 -servername example.com

Format Conversion

# PEM to DER
openssl x509 -in cert.pem -outform DER -out cert.der

# DER to PEM
openssl x509 -in cert.der -inform DER -outform PEM -out cert.pem

# PEM to PKCS12 (for browsers/Java)
openssl pkcs12 -export -out cert.p12 -inkey key.pem -in cert.pem -certfile chain.pem

# PKCS12 to PEM
openssl pkcs12 -in cert.p12 -out combined.pem -nodes

# Extract private key from PKCS12
openssl pkcs12 -in cert.p12 -nocerts -nodes -out key.pem

# Extract certificate from PKCS12
openssl pkcs12 -in cert.p12 -clcerts -nokeys -out cert.pem

Encryption and Hashing

# Hash a file
openssl dgst -sha256 file.txt
openssl dgst -sha512 file.txt

# Encrypt a file
openssl enc -aes-256-cbc -salt -in plaintext.txt -out encrypted.bin -pbkdf2
openssl enc -aes-256-cbc -d -in encrypted.bin -out decrypted.txt -pbkdf2

# Generate random password
openssl rand -base64 32
openssl rand -hex 16

# Base64 encode/decode
openssl base64 -in file.bin -out file.b64
openssl base64 -d -in file.b64 -out file.bin

Tips and Tricks

• Always use -nodes (no DES) in dev to skip passphrase prompts
• Use EC keys (prime256v1 or secp384r1) for better performance than RSA
• Check cert expiry in CI/CD: alert if under 30 days remaining
• Use openssl s_client to debug TLS handshake failures
• Modern best practice: TLS 1.3 only, ECDSA certificates
