Model Serving on OpenShift AI with vLLM

Deploying large language models in production requires more than just downloading weights and running inference. You need efficient memory management, request batching, and GPU utilization that justifies the hardware cost. vLLM on OpenShift AI gives you all of this with a production-grade serving stack.

Why vLLM

vLLM introduced PagedAttention, which manages the KV cache like virtual memory pages instead of allocating contiguous GPU memory blocks. This single innovation increased throughput by 2-4x compared to naive inference approaches.

Key capabilities:

• PagedAttention: efficient KV cache management, near-zero memory waste
• Continuous batching: new requests are added to running batches without waiting for the current batch to complete
• Tensor parallelism: split models across multiple GPUs automatically
• OpenAI-compatible API: drop-in replacement for OpenAI endpoints
• Quantization support: AWQ, GPTQ, and FP8 for running larger models on smaller GPUs

Prerequisites

Before deploying on OpenShift AI, you need:

• OpenShift 4.14+ with the OpenShift AI operator installed
• NVIDIA GPU Operator configured with your GPU nodes
• At least one node with NVIDIA A100, H100, or L40S GPUs
• A model stored in a PersistentVolume or accessible via S3-compatible storage

Deploying vLLM on OpenShift AI

Create the ServingRuntime

OpenShift AI uses ServingRuntime custom resources to define inference engines:

apiVersion: serving.kserve.io/v1alpha1
kind: ServingRuntime
metadata:
  name: vllm-runtime
  namespace: my-ai-project
spec:
  supportedModelFormats:
    - name: vllm
      version: "1"
      autoSelect: true
  multiModel: false
  containers:
    - name: kserve-container
      image: quay.io/modh/vllm:latest
      command:
        - python
        - -m
        - vllm.entrypoints.openai.api_server
      args:
        - --model=/mnt/models
        - --tensor-parallel-size=2
        - --max-model-len=4096
        - --gpu-memory-utilization=0.9
        - --dtype=float16
      resources:
        requests:
          nvidia.com/gpu: 2
          memory: 48Gi
          cpu: 8
        limits:
          nvidia.com/gpu: 2
          memory: 64Gi
          cpu: 16
      ports:
        - containerPort: 8000
          protocol: TCP
      volumeMounts:
        - name: model-storage
          mountPath: /mnt/models

Create the InferenceService

apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  name: llama-3-service
  namespace: my-ai-project
  annotations:
    serving.kserve.io/deploymentMode: RawDeployment
spec:
  predictor:
    model:
      modelFormat:
        name: vllm
      runtime: vllm-runtime
      storageUri: pvc://model-pvc/llama-3-8b

Verify the Deployment

# Check pod status
oc get pods -n my-ai-project

# Check the inference service
oc get inferenceservice llama-3-service -n my-ai-project

# Test the endpoint
curl -X POST \
  "https://llama-3-service-my-ai-project.apps.cluster.example.com/v1/completions" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "llama-3-8b",
    "prompt": "Explain Kubernetes in one paragraph:",
    "max_tokens": 200,
    "temperature": 0.7
  }'

GPU Memory Planning

Choosing the right configuration depends on your model size and GPU hardware:

For smaller GPUs like L40S (48GB) or A10G (24GB), use quantized models:

# AWQ quantized Llama 3 8B fits on a single 24GB GPU
--quantization awq --model TheBloke/Llama-3-8B-AWQ

Performance Tuning

Continuous Batching Configuration

# Increase max concurrent sequences for higher throughput
--max-num-seqs=256

# Set maximum number of batched tokens
--max-num-batched-tokens=8192

KV Cache Optimization

# Use 90% of GPU memory for KV cache (default is 0.9)
--gpu-memory-utilization=0.9

# Enable prefix caching for repeated prompts
--enable-prefix-caching

Monitoring with Prometheus

vLLM exposes Prometheus metrics out of the box. On OpenShift, connect these to the built-in monitoring stack:

apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: vllm-metrics
spec:
  selector:
    matchLabels:
      app: vllm
  endpoints:
    - port: metrics
      interval: 15s

Key metrics to watch:

• vllm:num_requests_running — active requests
• vllm:num_requests_waiting — queued requests
• vllm:gpu_cache_usage_perc — KV cache utilization
• vllm:avg_generation_throughput_toks_per_s — tokens per second

Autoscaling

Configure horizontal pod autoscaling based on GPU utilization or request queue depth:

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: vllm-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: llama-3-service-predictor
  minReplicas: 1
  maxReplicas: 4
  metrics:
    - type: Pods
      pods:
        metric:
          name: vllm_num_requests_waiting
        target:
          type: AverageValue
          averageValue: "10"

Automating Deployment with Ansible

For teams managing multiple models across environments, Ansible can automate the entire deployment lifecycle:

---
- name: Deploy vLLM model on OpenShift AI
  hosts: localhost
  vars:
    model_name: llama-3-8b
    namespace: my-ai-project
    gpu_count: 2
    model_pvc: model-pvc
  tasks:
    - name: Apply ServingRuntime
      kubernetes.core.k8s:
        state: present
        src: templates/vllm-runtime.yaml

    - name: Apply InferenceService
      kubernetes.core.k8s:
        state: present
        src: templates/inference-service.yaml

    - name: Wait for deployment
      kubernetes.core.k8s_info:
        api_version: serving.kserve.io/v1beta1
        kind: InferenceService
        name: "{{ model_name }}-service"
        namespace: "{{ namespace }}"
      register: isvc
      until: isvc.resources[0].status.conditions |
             selectattr('type', 'equalto', 'Ready') |
             selectattr('status', 'equalto', 'True') | list | length > 0
      retries: 30
      delay: 10

Final Thoughts

vLLM on OpenShift AI is the production-grade path for serving LLMs at scale. PagedAttention alone justifies the choice over naive serving approaches. Combined with OpenShift’s GPU scheduling, monitoring, and autoscaling, you get an enterprise-ready inference platform.

Start with a single GPU node for development, validate your throughput requirements, then scale horizontally with the HPA configuration. The OpenAI-compatible API means your application code does not need to change as you scale the infrastructure underneath.
