External GPU on Raspberry Pi 5 for Local LLM Inference with OpenClaw

The Dream: GPU-Accelerated AI on a Pi

Jeff Geerling proved that external GPUs work on Raspberry Pi 5 via the PCIe slot. AMD cards, Intel Arc, even NVIDIA (with effort). But can you actually run LLM inference on a Pi-attached GPU? I tested it with OpenClaw.

Hardware

- Raspberry Pi 5 (8GB)
- PCIe to x16 adapter (via M.2 HAT)
- AMD Radeon RX 6400 (4GB VRAM)
- Powered PCIe riser + ATX PSU
- Total cost: ~$200 (Pi + GPU + adapters)

Getting the GPU Working

Follow Jeff’s guide for AMD GPU setup on Pi OS:

# Enable PCIe Gen 3
echo "dtparam=pciex1_gen=3" | sudo tee -a /boot/firmware/config.txt
sudo reboot

# Verify GPU is detected
lspci | grep -i vga
# 01:00.0 VGA compatible controller: AMD/ATI Navi 24 [Radeon RX 6400]

# Install ROCm (AMD's GPU compute stack)
# Note: ARM64 ROCm support is experimental
wget https://repo.radeon.com/rocm/apt/latest/pool/main/r/rocm-hip-runtime/...

The Challenge: ROCm on ARM64

Here’s where reality hits. ROCm’s ARM64 support is limited. llama.cpp’s ROCm backend expects x86_64. You need to compile from source with the right flags:

git clone https://github.com/ggerganov/llama.cpp
cd llama.cpp
cmake -B build -DGGML_HIPBLAS=ON -DCMAKE_C_COMPILER=hipcc
cmake --build build --config Release

This may or may not work depending on your ROCm version and the GPU generation. The RX 6400 is gfx1032 — not always officially supported.

What Actually Worked

After significant effort, I got llama.cpp running with partial GPU offload:

./build/bin/llama-server \
  -m models/phi-3-mini-4k-instruct-q4_0.gguf \
  -ngl 20 \  # Offload 20 layers to GPU
  -c 2048 \
  --port 8080

Performance with 4GB VRAM RX 6400:

Phi-3 3.8B (Q4_0):
  CPU only (Pi 5):    4.5 tok/s
  GPU offload (20L):  7.2 tok/s  (+60%)
  Full GPU:           Not possible (4GB VRAM too small)

Mistral 7B (Q4_0):
  CPU only:           2.1 tok/s
  GPU offload (15L):  3.8 tok/s  (+80%)

Connecting to OpenClaw

# openclaw.yaml
providers:
  local-gpu:
    type: openai-compatible
    baseUrl: http://localhost:8080/v1

models:
  default: github-copilot/gpt-5-mini
  local: local-gpu/phi-3-mini

Is It Worth It?

Honestly? No. Here’s why:

1. $200 for 7 tok/s — GPT-5-mini gives 50+ tok/s for $10/month
2. Power draw — the GPU alone uses 50W. The Pi uses 5W
3. Complexity — ROCm on ARM64 is fragile, updates break things
4. Quality — Phi-3 at Q4 can’t match GPT-5-mini for tool calling

But it’s cool as hell. And when AMD releases a 16GB card in the $150 range, and ROCm ARM64 matures, this setup will actually be practical.

The Better Option (Today)

For the same $200:

• Raspberry Pi 5 (8GB): $80
• 2 years of Copilot Pro: $120
• Result: 50+ tok/s, state-of-the-art quality, zero maintenance

The eGPU-on-Pi experiment is a glimpse of the future. But the future isn’t quite here yet.
