Run:ai Topology-Aware Scheduling for GPU Workloads (2026)

When a distributed workload spans multiple nodes, where those nodes sit in the network determines performance. Pods in the same rack communicate over high-speed switches. Pods across racks hit bandwidth bottlenecks. Pods across zones add milliseconds of latency that compound across thousands of gradient synchronization steps.

NVIDIA Run:ai’s topology-aware scheduling solves this by using knowledge of your cluster’s physical network layout to place workload pods on nodes that minimize communication overhead.

Why Topology Matters

A modern GPU cluster has a hierarchy:

Region (eu-west)
└── Zone (eu-west-1a)
    └── Block (block-3)
        └── Rack (rack-42)
            └── Node (gpu-node-07)
                └── GPU (NVLink domain)

Each level has different bandwidth and latency characteristics:

A workload placed entirely within one rack gets 10-100x better inter-node bandwidth than one scattered across racks. For distributed training with all-reduce operations or disaggregated inference with NIXL transfers, this difference is enormous.

How It Works

1. Label Your Nodes

Topology-aware scheduling relies on Kubernetes node labels that describe physical location. These can be:

• Manual: Apply labels with kubectl
• Automatic (cloud): Cloud providers often set zone/region labels automatically
• Discovery tools: NVIDIA Topograph can detect topology from hardware, optionally integrating with NVIDIA NetQ for on-prem environments

# Manual labeling example
kubectl label node gpu-node-01 \
  topology.kubernetes.io/region=eu-west \
  topology.kubernetes.io/zone=eu-west-1a \
  cloud.provider.com/topology-block=block-3 \
  cloud.provider.com/topology-rack=rack-42

2. Define Network Topology in Run:ai

Create a topology that maps label keys from farthest to closest:

{
  "levels": [
    "topology.kubernetes.io/region",
    "topology.kubernetes.io/zone",
    "cloud.provider.com/topology-block",
    "cloud.provider.com/topology-rack",
    "kubernetes.io/hostname"
  ],
  "name": "default-topology",
  "clusterId": "<CLUSTER_ID>"
}

Order matters: First label = farthest (region), last label = closest (hostname).

3. Attach Topology to Node Pools

• Single node pool: Attach topology to the default pool
• Multiple pools with same topology: Link the same topology to all pools
• Different hardware, different topology: Each pool gets its own topology definition

4. Automatic Scheduling

Once configured, distributed workloads automatically get topology-aware placement. No annotations needed. Run:ai applies a Preferred constraint at the lowest topology level and escalates upward if placement is not possible:

Try: Same hostname → Same rack → Same block → Same zone → Same region

Fine-Tuning Placement per Workload

Override the automatic behavior with annotations:

Preferred (Soft Constraint)

Best-effort co-location. Scheduler tries the specified level but relaxes if needed:

metadata:
  annotations:
    kai.scheduler/topology: "default-topology"
    kai.scheduler/topology-preferred-placement: "cloud.provider.com/topology-rack"

Required (Hard Constraint)

Strict placement. All pods must be in the same topology level or the workload waits:

metadata:
  annotations:
    kai.scheduler/topology: "default-topology"
    kai.scheduler/topology-required-placement: "topology.kubernetes.io/zone"

Combined (Required + Preferred)

Enforce a broad constraint while preferring a tighter one:

metadata:
  annotations:
    kai.scheduler/topology: "default-topology"
    kai.scheduler/topology-required-placement: "topology.kubernetes.io/zone"
    kai.scheduler/topology-preferred-placement: "cloud.provider.com/topology-rack"

This means: all pods must be in the same zone, and the scheduler tries to put them in the same rack within that zone.

Important: A Preferred constraint at the same level or higher than Required has no effect. Preferred only works at a lower (more specific) level.

LeaderWorkerSet Behavior

For LeaderWorkerSet workloads (used by NIM multi-node, Dynamo), topology-aware scheduling is applied per replica:

apiVersion: leaderworkerset.x-k8s.io/v1
kind: LeaderWorkerSet
metadata:
  annotations:
    kai.scheduler/topology: "cluster-topology"
    kai.scheduler/topology-required-placement: "cloud.provider.com/topology-block"
    kai.scheduler/topology-preferred-placement: "cloud.provider.com/topology-rack"
  labels:
    runai/queue: production
  namespace: runai-production
  name: llm-inference
spec:
  replicas: 2
  leaderWorkerTemplate:
    size: 2

Each replica (leader + workers) is:

1. Gang scheduled — all pods in a replica launch together
2. Topology constrained — leader and worker pods land on the same rack/block

With 2 replicas of size 2, you get 4 pods total. Each pair of 2 is co-located, but the two replicas may be on different racks.

Pod Affinity vs Topology-Aware Scheduling

Standard Kubernetes pod affinity has a fundamental flaw for distributed workloads: it places pods one by one, checking closeness to already-placed pods without seeing the full picture.

Example: Two racks, some nodes already occupied. A workload needs 6 nodes.

Topology-aware scheduling evaluates the entire workload against available resources before making any placement decision. Pod affinity is greedy and local.

Practical Recommendations

For Distributed Training

# Strict same-rack, all GPUs need high-bandwidth all-reduce
annotations:
  kai.scheduler/topology: "cluster-topology"
  kai.scheduler/topology-required-placement: "cloud.provider.com/topology-rack"

For Disaggregated Inference (Dynamo)

# Same zone required, same rack preferred
# Prefill and decode need fast NIXL transfers but can tolerate rack-level latency
annotations:
  kai.scheduler/topology: "cluster-topology"
  kai.scheduler/topology-required-placement: "topology.kubernetes.io/zone"
  kai.scheduler/topology-preferred-placement: "cloud.provider.com/topology-rack"

For GB200 NVL72

For multi-node NVLink domains, see the GB200 and Multi-Node NVLink guide. The topology must reflect NVLink domain boundaries.

Known Limitations

• Detaching a topology from a node pool does not affect running workloads (they continue using it)
• Deleting a topology while workloads reference it: running workloads continue, but suspended/unbound workloads become unschedulable (Pending)
• Submitting a workload to multiple node pools with different topologies is not supported — workloads will fail or remain pending
