NVIDIA NIM Multi-Node on Kubernetes: 400B+ Model Deployment

When a model does not fit on a single node, you need multi-node deployment. NIM LLM uses Ray for cluster formation and vLLM for distributed execution across nodes. The Helm chart wraps all of this into a LeaderWorkerSet that you deploy with one command.

This guide covers the official NIM multi-node deployment on Kubernetes — the Helm-native approach using Ray, as distinct from the Run:ai orchestrated approach or bare Docker deployment.

Architecture

NIM multi-node uses a leader/worker model:

┌────────────────────────────┐
│  Leader Node               │
│  ┌──────────┐ ┌──────────┐│
│  │ Ray Head │ │ vLLM     ││
│  │ :6379    │ │ Server   ││
│  └──────────┘ │ :8000    ││
│               └──────────┘│
│  8× GPU (TP=8, stage 0)   │
└─────────┬──────────────────┘
          │ Ray cluster + NCCL
┌─────────▼──────────────────┐
│  Worker Node 1             │
│  ┌──────────┐              │
│  │Ray Worker│              │
│  └──────────┘              │
│  8× GPU (TP=8, stage 1)   │
└────────────────────────────┘

The same container image runs on both leader and worker. The role is determined by the command injected at deployment time via the LeaderWorkerSet controller.

Leader starts a Ray head node, downloads the model, and launches vLLM with distributed execution. Workers join the Ray cluster and provide GPU resources. vLLM spawns execution actors on worker nodes for model parallelism.

Parallelism Strategies

Two strategies split model weights across nodes:

The standard configuration: TP = GPUs per node, PP = number of nodes.

For Llama 3.1 405B on two 8-GPU nodes:

• TP = 8 (split layers across 8 GPUs per node)
• PP = 2 (split model into 2 pipeline stages, one per node)
• Total: 16 GPUs

Multi-Node Tensor Parallelism

In some cases, you can use TP across nodes instead of PP:

• TP = 16, PP = 1
• One tensor-parallel group spans 2 nodes

This requires InfiniBand with RDMA — the continuous cross-node GPU communication demands high bandwidth and low latency that Ethernet cannot deliver.

Prerequisites

1. Kubernetes cluster with GPU nodes (same GPU type and count per node)

2. LeaderWorkerSet CRD installed:

kubectl apply --server-side -f \
  https://github.com/kubernetes-sigs/lws/releases/latest/download/manifests.yaml

3. Shared storage — PVC with ReadWriteMany access mode (recommended)

4. High-speed networking — InfiniBand or RoCE for optimal NCCL performance

5. NGC API key as Kubernetes secret:

kubectl create secret generic ngc-api \
  --from-literal=NGC_API_KEY=<your-key>

Deploy with Helm

Minimal Configuration

Create values.yaml:

image:
  repository: nvcr.io/nim/meta/llama-3.1-405b-instruct
  tag: "latest"

model:
  ngcAPISecret: ngc-api
  jsonLogging: false  # REQUIRED: JSON logging breaks Ray workers

multiNode:
  enabled: true
  workers: 1                  # Worker pods (total nodes = workers + 1 leader)
  tensorParallelSize: 8       # GPUs per tensor-parallel group
  pipelineParallelSize: 2     # Pipeline stages (typically = number of nodes)

resources:
  limits:
    nvidia.com/gpu: 8
  requests:
    nvidia.com/gpu: 8

persistence:
  enabled: true
  size: 200Gi
  accessMode: ReadWriteMany   # REQUIRED for multi-node shared storage
  storageClass: <your-rwx-storage-class>

imagePullSecrets:
  - name: nvcr-imagepull

Install:

helm install nim-llm nim-llm/ -f values.yaml

Critical: Set model.jsonLogging: false. The NIM JSON log formatter is not available in vLLM Ray worker processes and causes worker initialization to fail.

Profile Selection

Two approaches — pick one:

Option A: TP/PP Values (Recommended)

Set tensorParallelSize and pipelineParallelSize. The Helm chart injects NIM_TENSOR_PARALLEL_SIZE and NIM_PIPELINE_PARALLEL_SIZE environment variables. The correct model profile is selected automatically.

helm install nim-llm nim-llm/ \
  --set multiNode.enabled=true \
  --set multiNode.workers=1 \
  --set multiNode.tensorParallelSize=8 \
  --set multiNode.pipelineParallelSize=2

Option B: Explicit Profile

Set model.profile to a profile name or hash. The chart injects NIM_MODEL_PROFILE:

helm install nim-llm nim-llm/ \
  --set multiNode.enabled=true \
  --set multiNode.workers=1 \
  --set model.profile=vllm-fp16-tp8-pp2

You must use one of these approaches. The chart will fail to render if neither TP/PP nor model.profile is set.

Helm Values Reference

Model Storage

Shared Storage (Recommended)

With a ReadWriteMany PVC or NFS:

1. Leader downloads model once to shared volume
2. Workers detect cached blobs and materialize a local workspace at /tmp/nim_workspace — no network download

Two backends:

PVC with existingClaim — pre-create a RWX PVC. It survives helm uninstall, so the model cache persists across deployments:

persistence:
  enabled: true
  existingClaim: nim-model-cache
  accessMode: ReadWriteMany

NFS direct mount:

nfs:
  enabled: true
  server: nfs-server.internal
  path: /exports/nim-models

Independent Downloads (Not Recommended)

Without shared storage, each node downloads the model independently to emptyDir. This works but wastes time and bandwidth — Llama 405B is ~400 GB, downloaded N+1 times instead of once.

Model-Free Multi-Node

Deploy any HuggingFace model across nodes using model-free NIM:

image:
  repository: nvcr.io/nim/nim-llm
  tag: "latest"

model:
  modelPath: "hf://meta-llama/Llama-3.1-405B-Instruct"
  ngcAPISecret: ngc-api
  hfTokenSecret: hf-token
  jsonLogging: false

multiNode:
  enabled: true
  workers: 1
  tensorParallelSize: 8
  pipelineParallelSize: 2

persistence:
  enabled: true
  size: 200Gi
  accessMode: ReadWriteMany
  storageClass: local-nfs

This uses the generic NIM container (nim-llm) instead of a model-specific container, and generates profiles at runtime.

NIM Operator Deployment

The NIM Operator provides a fully automated alternative:

• Manages NIMService custom resource
• Automatically generates leader/worker pod specs
• Injects Ray startup commands
• Handles PVC setup through NIMCache
• Manages probes, networking, and secrets

If you are running NIM at scale across multiple models, the Operator reduces operational overhead compared to managing individual Helm releases.

Common Configurations

Llama 3.1 405B — 2 Nodes (TP=8, PP=2)

The standard configuration. Two 8-GPU nodes, 16 GPUs total:

multiNode:
  enabled: true
  workers: 1
  tensorParallelSize: 8
  pipelineParallelSize: 2

DeepSeek-R1 671B — 2 Nodes (TP=8, PP=2)

Same parallelism but larger model, needs more storage:

image:
  repository: nvcr.io/nim/deepseek-ai/deepseek-r1
  tag: "latest"

persistence:
  size: 500Gi  # DeepSeek-R1 is ~650 GB

Multi-Node TP — 2 Nodes (TP=16, PP=1)

Single TP group spanning both nodes. Requires InfiniBand:

multiNode:
  enabled: true
  workers: 1
  tensorParallelSize: 16
  pipelineParallelSize: 1

4-Node Deployment (TP=8, PP=4)

Four nodes for extremely large models or higher throughput:

multiNode:
  enabled: true
  workers: 3           # 3 workers + 1 leader = 4 nodes
  tensorParallelSize: 8
  pipelineParallelSize: 4

resources:
  limits:
    nvidia.com/gpu: 8

Troubleshooting

Workers Cannot Join Ray Cluster

# Check worker logs for Ray connection errors
kubectl logs <worker-pod-name>

# Verify Ray port (6379) is accessible between pods
kubectl exec <leader-pod> -- nc -zv <worker-pod-ip> 6379

# Check LWS_LEADER_ADDRESS injection
kubectl get pods -o yaml | grep LWS_LEADER_ADDRESS

Common causes: network policies blocking port 6379, LWS controller not running, DNS resolution issues.

Model Download Failures

# Verify NGC secret
kubectl get secret ngc-api -o jsonpath='{.data.NGC_API_KEY}' | base64 -d

# Check PVC is bound with correct access mode
kubectl get pvc

NCCL Communication Errors

# Enable NCCL debug logging
env:
  - name: NCCL_DEBUG
    value: "INFO"
  - name: NCCL_IB_DISABLE
    value: "0"  # Ensure InfiniBand is enabled

For multi-node TP, InfiniBand/RoCE is effectively required. Ethernet will work but with severe performance degradation.

JSON Logging Crash

If workers crash immediately at startup, check if jsonLogging is enabled:

model:
  jsonLogging: false  # MUST be false for multi-node

The NIM JSON log formatter does not exist in vLLM Ray worker processes.
