NIM Model Profiles: GPU Memory and Selection Guide

Every NIM LLM container ships with a model manifest — a catalog of pre-validated configurations called profiles. When the container starts, NIM selects exactly one profile. That profile determines which model files get downloaded and how the inference backend launches.

Getting this right matters. Pick the wrong profile and you waste GPU memory, hit OOM errors, or run at half the throughput your hardware can deliver.

Profile Naming Convention

Profiles follow a predictable naming pattern:

vllm-<precision>-tp<N>-pp1[-lora]

Examples:

• vllm-bf16-tp1-pp1 — BF16 on 1 GPU, no LoRA
• vllm-fp8-tp4-pp1-lora — FP8 quantized across 4 GPUs with LoRA
• sglang-h100-bf16-tp8-pp2 — SGLang on 8 GPUs with 2-stage pipeline (used for DeepSeek-R1 multinode)

The naming tells you exactly what you are getting: precision, GPU count, and capabilities.

Listing Available Profiles

Before deploying, check which profiles your container supports and which are compatible with your hardware:

docker run --rm --gpus=all \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest \
  list-model-profiles

Output groups profiles into three categories:

MODEL PROFILES
- Compatible with system and runnable:
  - dcec66a5... (vllm-bf16-tp1-pp1) [requires >=18 GB/gpu]
  - With LoRA support:
    - d66193b8... (vllm-bf16-tp1-pp1-feat_lora) [requires >=22 GB/gpu]

- Compatible with system but low memory:
  - a1b2c3d4... (vllm-bf16-tp1-pp1) [requires >=45 GB/gpu,
    try --max-model-len=4096 to reduce to >=30 GB/gpu]

- Incompatible with system:
  - 27af459c... (vllm-bf16-tp2-pp1)
  - 30d16624... (vllm-bf16-tp4-pp1)

Each profile shows:

• Profile ID — a unique 64-character SHA hash (deterministic, version-safe)
• Description — the human-readable name (vllm-bf16-tp1-pp1)
• Memory annotation — estimated VRAM requirement per GPU

Memory-Based Classification

NIM estimates GPU VRAM for each profile by analyzing model weights, KV cache, activations, and overhead. Then classifies:

For low-memory profiles, NIM tells you exactly what to do:

[requires >=45 GB/gpu, try --max-model-len=4096 to reduce to >=30 GB/gpu]

Apply the suggestion:

docker run --rm -it --gpus=all \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest \
  --max-model-len 4096

Reducing --max-model-len limits the maximum sequence length (input + output tokens) per request. A 70B model at BF16 with 4096 context fits on a single A100 80GB. At 128K context, it needs 4+ GPUs.

The Selection Chain

NIM uses a priority-ordered selection chain. The first selector that produces a match wins:

Automatic Selection (Most Common)

If you do not set NIM_MODEL_PROFILE, NIM automatically picks the best profile for your hardware:

docker run --rm -it --gpus=all \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest

NIM evaluates GPU device, available VRAM, and parallelism constraints. For most deployments, this is sufficient.

Intelligent Default

Setting NIM_MODEL_PROFILE="default" triggers a slightly different path — it uses backend priority ordering:

docker run --rm -it --gpus=all \
  -e NIM_MODEL_PROFILE="default" \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest

Explicit Selection by Profile ID

For production, pin to a specific profile ID. This is deterministic and version-safe — the profile is guaranteed to match even if tags change in a future release:

docker run --rm -it --gpus=all \
  -e NIM_MODEL_PROFILE="70edb8bb9f8511ce2ea195e3caebcc3c7191dc27fea0c8d4acf9c0d9a69e43cd" \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest

Explicit Selection by Description

If the value is not a valid profile ID, NIM tries to match it against descriptions:

docker run --rm -it --gpus=all \
  -e NIM_MODEL_PROFILE="vllm-fp8-tp4-pp1" \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest

This is what we use in the Run:ai distributed inference tutorial with NIM_MODEL_PROFILE=sglang-h100-bf16-tp8-pp2 for DeepSeek-R1.

Configuration Precedence

Backend-native arguments always override profile settings:

Backend CLI args (highest) > NIM_MODEL_PROFILE (lower)

If a profile specifies tp=2 but you pass --tensor-parallel-size 4, the backend launches with TP=4. NIM resolves the overridden values before model download, so the downloaded model files always match the actual launch configuration.

Common vLLM CLI Overrides

Example — override tensor parallelism:

docker run --rm -it --gpus=all \
  -p 8000:8000 \
  nvcr.io/nim/meta/llama-3.1-70b-instruct:latest \
  --tensor-parallel-size 2

Precision Selection Guide

Choosing the right precision is a tradeoff between quality, memory, and throughput:

Recommendation: Use FP8 for production. It halves memory requirements with negligible quality loss, effectively doubling the models you can serve per GPU.

Practical Decision Tree

Do you need LoRA adapters?
├── Yes → Select a -lora profile
└── No → Continue

How many GPUs per node?
├── 1 GPU → tp1
├── 2 GPUs → tp2
├── 4 GPUs → tp4
└── 8 GPUs → tp8

Does the model fit at bf16?
├── Yes (comfortable) → bf16
├── Yes (tight) → fp8 for headroom
└── No → fp8 or fp4

Multi-node needed? (model exceeds single node)
├── Yes → Set pp>1 + NIM_MULTI_NODE=1
└── No → pp1

Production deployment?
├── Yes → Pin profile by ID
└── Dev/test → Automatic selection is fine

Changes from NIM 1.x

If you are migrating from NIM LLM 1.x, these features are removed:

Replace all of these with NIM_MODEL_PROFILE using a profile ID or description.
