NVIDIA Network Operator: RDMA on Kubernetes

Distributed AI training performance is limited by how fast GPUs on different nodes can communicate. The NVIDIA Network Operator deploys and manages the networking stack required for RDMA (Remote Direct Memory Access) on Kubernetes, enabling GPU-to-GPU transfers that bypass the CPU entirely.

What the Network Operator Manages

The Network Operator is a Kubernetes operator that automates deployment of:

• MOFED Drivers: Mellanox OFED kernel drivers for InfiniBand and RoCE
• RDMA Shared Device Plugin: exposes RDMA devices as Kubernetes resources
• SR-IOV Network Operator: manages SR-IOV VFs for dedicated pod networking
• IB Kubernetes Plugin: InfiniBand network plugin for pod connectivity
• Multus CNI: enables multiple network interfaces per pod
• Container Networking Plugins: secondary network configuration

Installation

helm repo add nvidia https://helm.ngc.nvidia.com/nvidia
helm repo update

helm install network-operator nvidia/network-operator \
  --namespace nvidia-network-operator \
  --create-namespace \
  --set nfd.enabled=true \
  --set ofedDriver.deploy=true \
  --set rdmaSharedDevicePlugin.deploy=true \
  --set sriovNetworkOperator.enabled=true \
  --set secondaryNetwork.deploy=true \
  --set secondaryNetwork.multus.deploy=true

NicClusterPolicy

The central configuration resource:

apiVersion: mellanox.com/v1alpha1
kind: NicClusterPolicy
metadata:
  name: nic-cluster-policy
spec:
  ofedDriver:
    image: doca-driver
    repository: nvcr.io/nvidia/mellanox
    version: 24.07-0.6.1.0-0
    upgradePolicy:
      autoUpgrade: true
      maxParallelUpgrades: 1
      drain:
        enable: true
        force: true
        timeoutSeconds: 300

  rdmaSharedDevicePlugin:
    image: k8s-rdma-shared-dev-plugin
    repository: ghcr.io/mellanox
    version: v1.5.1
    config: |
      {
        "periodicUpdateInterval": 300,
        "configList": [
          {
            "resourceName": "rdma_shared_device_a",
            "rdmaHcaMax": 63,
            "selectors": {
              "vendors": ["15b3"]
            }
          }
        ]
      }

  secondaryNetwork:
    cniPlugins:
      image: plugins
      repository: ghcr.io/k8snetworkplumbingwg
      version: v1.5.0
    multus:
      image: multus-cni
      repository: ghcr.io/k8snetworkplumbingwg
      version: v4.0.2
    ipamPlugin:
      image: whereabouts
      repository: ghcr.io/k8snetworkplumbingwg
      version: v0.7.0

RDMA Network Configuration

MacVLAN for RDMA

For shared RDMA access without SR-IOV:

apiVersion: k8s.cni.cncf.io/v1
kind: NetworkAttachmentDefinition
metadata:
  name: rdma-macvlan
  namespace: ai-training
spec:
  config: |
    {
      "cniVersion": "0.3.1",
      "type": "macvlan",
      "master": "ens3f0",
      "mode": "bridge",
      "ipam": {
        "type": "whereabouts",
        "range": "192.168.200.0/24"
      }
    }

IPoIB for InfiniBand

For InfiniBand networks:

apiVersion: k8s.cni.cncf.io/v1
kind: NetworkAttachmentDefinition
metadata:
  name: ib-network
  namespace: ai-training
spec:
  config: |
    {
      "cniVersion": "0.3.1",
      "type": "ib-sriov",
      "ibKubernetesEnabled": true,
      "ipam": {
        "type": "whereabouts",
        "range": "10.56.217.0/24"
      }
    }

Multi-Node Training with RDMA

Deploy a distributed PyTorch training job using RDMA:

apiVersion: batch/v1
kind: Job
metadata:
  name: distributed-training
  namespace: ai-training
spec:
  parallelism: 4
  template:
    metadata:
      annotations:
        k8s.v1.cni.cncf.io/networks: rdma-macvlan
    spec:
      containers:
        - name: trainer
          image: nvcr.io/nvidia/pytorch:24.07-py3
          command:
            - torchrun
            - --nnodes=4
            - --nproc_per_node=8
            - --rdzv_backend=c10d
            - --rdzv_endpoint=trainer-0:29500
            - train.py
          resources:
            limits:
              nvidia.com/gpu: 8
              rdma/rdma_shared_device_a: 1
          env:
            - name: NCCL_IB_DISABLE
              value: "0"
            - name: NCCL_NET_GDR_LEVEL
              value: "5"
            - name: NCCL_IB_HCA
              value: "mlx5"
            - name: NCCL_SOCKET_IFNAME
              value: "net1"
            - name: NCCL_DEBUG
              value: "INFO"
      restartPolicy: Never

NCCL Environment Variables

Critical NCCL settings for RDMA performance:

env:
  # Enable InfiniBand
  - name: NCCL_IB_DISABLE
    value: "0"

  # GPUDirect RDMA level (5 = max)
  - name: NCCL_NET_GDR_LEVEL
    value: "5"

  # Specify InfiniBand HCA
  - name: NCCL_IB_HCA
    value: "mlx5_0,mlx5_1"

  # Use secondary network for NCCL
  - name: NCCL_SOCKET_IFNAME
    value: "net1"

  # Number of RDMA QPs per connection
  - name: NCCL_IB_QPS_PER_CONNECTION
    value: "4"

  # Enable adaptive routing (if switch supports it)
  - name: NCCL_IB_ADAPTIVE_ROUTING
    value: "1"

Verifying RDMA Performance

ib_write_bw Benchmark

# On node 1 (server)
kubectl exec -it rdma-test-node1 -- ib_write_bw -d mlx5_0

# On node 2 (client)
kubectl exec -it rdma-test-node2 -- ib_write_bw -d mlx5_0 192.168.200.1

# Expected: ~24 GB/s for HDR InfiniBand, ~48 GB/s for NDR

NCCL Tests

# All-reduce bandwidth test across 4 nodes x 8 GPUs
mpirun -np 32 -hostfile hosts \
  --mca btl_openib_allow_ib true \
  nccl-tests/build/all_reduce_perf -b 8 -e 2G -f 2 -g 1

Monitoring

# Check InfiniBand port status
kubectl exec -it mofed-pod -- ibstat

# Monitor port counters
kubectl exec -it mofed-pod -- perfquery

# Check for errors
kubectl exec -it mofed-pod -- ibdiagnet

Automating with Ansible

Deploy the Network Operator across clusters with Ansible:

---
- name: Deploy NVIDIA Network Operator
  hosts: localhost
  tasks:
    - name: Add NVIDIA Helm repo
      kubernetes.core.helm_repository:
        name: nvidia
        repo_url: https://helm.ngc.nvidia.com/nvidia

    - name: Install Network Operator
      kubernetes.core.helm:
        name: network-operator
        chart_ref: nvidia/network-operator
        release_namespace: nvidia-network-operator
        create_namespace: true
        values:
          ofedDriver:
            deploy: true
          rdmaSharedDevicePlugin:
            deploy: true
          sriovNetworkOperator:
            enabled: true

    - name: Apply NicClusterPolicy
      kubernetes.core.k8s:
        state: present
        src: manifests/nic-cluster-policy.yaml

Final Thoughts

The Network Operator is the networking counterpart to the GPU Operator. Together they automate the entire GPU infrastructure stack on Kubernetes — from drivers and device plugins to RDMA networking and monitoring. For any multi-node GPU deployment, the Network Operator is not optional. It is the difference between GPU nodes that can communicate at 24 GB/s over InfiniBand and nodes bottlenecked at 3 GB/s over TCP.
