NVIDIA GPU Operator MOFED Driver Policy on K8s

When you are running large-scale AI training on Kubernetes, the network between your GPU nodes matters as much as the GPUs themselves. Mellanox OFED (MOFED) drivers enable InfiniBand and RDMA networking that delivers the bandwidth and latency your distributed training workloads need. The NVIDIA GPU Operator can manage these drivers through the Network Operator and ClusterPolicy configuration.

Why MOFED Matters for GPU Workloads

Standard Ethernet networking introduces significant overhead for GPU-to-GPU communication in distributed training. RDMA (Remote Direct Memory Access) via InfiniBand or RoCE bypasses the CPU entirely, allowing GPUs on different nodes to communicate directly:

• InfiniBand HDR: 200 Gbps per port
• InfiniBand NDR: 400 Gbps per port
• RoCE v2: RDMA over standard Ethernet infrastructure
• GPUDirect RDMA: GPU memory accessed directly by the network adapter, zero CPU copies

Without MOFED drivers, you cannot use RDMA. Without RDMA, multi-node training on large models like Llama 3 70B+ is bottlenecked by the network.

Architecture Overview

The GPU Operator works alongside the NVIDIA Network Operator to manage both GPU and networking components:

NVIDIA GPU Operator          NVIDIA Network Operator
├── GPU Driver               ├── MOFED Driver
├── Container Toolkit         ├── RDMA Shared Device Plugin
├── Device Plugin            ├── SR-IOV Network Operator
├── DCGM Exporter            ├── IB Kubernetes Plugin
├── MIG Manager              └── Multus CNI
└── GDS Driver

Installing the Network Operator with MOFED

Deploy the Network Operator

helm repo add nvidia https://helm.ngc.nvidia.com/nvidia
helm repo update

helm install network-operator nvidia/network-operator \
  --namespace nvidia-network-operator \
  --create-namespace \
  --set deployCR=true \
  --set nfd.enabled=false \
  --set ofedDriver.deploy=true \
  --set rdmaSharedDevicePlugin.deploy=true

Configure the NicClusterPolicy for MOFED

The NicClusterPolicy custom resource controls MOFED driver deployment:

apiVersion: mellanox.com/v1alpha1
kind: NicClusterPolicy
metadata:
  name: nic-cluster-policy
spec:
  ofedDriver:
    image: doca-driver
    repository: nvcr.io/nvidia/mellanox
    version: 24.07-0.6.1.0-0
    startupProbe:
      initialDelaySeconds: 10
      periodSeconds: 20
    livenessProbe:
      initialDelaySeconds: 30
      periodSeconds: 30
    readinessProbe:
      initialDelaySeconds: 10
      periodSeconds: 30
    upgradePolicy:
      autoUpgrade: true
      maxParallelUpgrades: 1
      drain:
        enable: true
        force: true
        podSelector: ""
        timeoutSeconds: 300
        deleteEmptyDir: true
  rdmaSharedDevicePlugin:
    image: k8s-rdma-shared-dev-plugin
    repository: ghcr.io/mellanox
    version: v1.5.1
    config: |
      {
        "periodicUpdateInterval": 300,
        "configList": [
          {
            "resourceName": "rdma_shared_device_a",
            "rdmaHcaMax": 63,
            "selectors": {
              "vendors": ["15b3"],
              "deviceIDs": ["101b"]
            }
          }
        ]
      }

MOFED Driver Policy Options

Auto-Upgrade Policy

Control how MOFED driver updates are rolled out across the cluster:

spec:
  ofedDriver:
    upgradePolicy:
      autoUpgrade: true
      maxParallelUpgrades: 1  # Upgrade one node at a time
      drain:
        enable: true          # Drain node before upgrade
        force: true           # Force drain even with local storage
        timeoutSeconds: 300   # Wait up to 5 minutes for drain
        deleteEmptyDir: true  # Allow draining pods with emptyDir

Setting maxParallelUpgrades: 1 ensures you never lose more than one node during a rolling driver upgrade — critical for production GPU clusters where every node represents significant compute capacity.

Version Pinning

Pin the MOFED driver version to ensure consistency:

spec:
  ofedDriver:
    version: "24.07-0.6.1.0-0"  # Pin to a specific version

Check compatibility between MOFED version, GPU driver version, and kernel version before upgrading. The NVIDIA compatibility matrix documents supported combinations.

Custom Kernel Module Parameters

Pass parameters to the MOFED kernel modules:

spec:
  ofedDriver:
    env:
      - name: CREATE_IFNAMES_UDEV
        value: "true"
      - name: UNLOAD_STORAGE_MODULES
        value: "true"

Verifying MOFED Installation

# Check MOFED driver pods
kubectl get pods -n nvidia-network-operator -l app=mofed

# Verify driver is loaded on a node
kubectl exec -n nvidia-network-operator mofed-xxxx -- ofed_info -s
# Expected: MLNX_OFED_LINUX-24.07-0.6.1.0

# Check InfiniBand devices
kubectl exec -n nvidia-network-operator mofed-xxxx -- ibstat

Integrating with GPU Operator

When both operators are deployed, configure the GPU Operator to use the Network Operator’s MOFED drivers:

helm install gpu-operator nvidia/gpu-operator \
  --namespace gpu-operator \
  --create-namespace \
  --set driver.enabled=true \
  --set driver.rdma.enabled=true \
  --set driver.rdma.useHostMofed=true

The useHostMofed: true setting tells the GPU driver container to use the MOFED drivers installed by the Network Operator rather than bundling its own.

Testing RDMA Connectivity

Deploy a test pod to verify RDMA is working:

apiVersion: v1
kind: Pod
metadata:
  name: rdma-test
spec:
  containers:
    - name: rdma-test
      image: mellanox/rping-test
      command: ["sleep", "infinity"]
      resources:
        limits:
          rdma/rdma_shared_device_a: 1
          nvidia.com/gpu: 1

kubectl exec -it rdma-test -- ibv_devinfo
# Should show InfiniBand device details with active port

Performance Considerations

For distributed AI training workloads:

• Use NCCL with the RDMA transport for multi-node GPU communication
• Set NCCL_IB_DISABLE=0 and NCCL_NET_GDR_LEVEL=5 for GPUDirect RDMA
• Monitor InfiniBand port errors with perfquery
• Use ibdiagnet for fabric-level diagnostics

# Example training pod environment variables
env:
  - name: NCCL_IB_DISABLE
    value: "0"
  - name: NCCL_NET_GDR_LEVEL
    value: "5"
  - name: NCCL_IB_HCA
    value: "mlx5"
  - name: NCCL_DEBUG
    value: "INFO"

Automating with Ansible

Scale MOFED deployment across multiple clusters with Ansible:

---
- name: Deploy NVIDIA Network Operator with MOFED
  hosts: localhost
  tasks:
    - name: Install Network Operator
      kubernetes.core.helm:
        name: network-operator
        chart_ref: nvidia/network-operator
        release_namespace: nvidia-network-operator
        create_namespace: true
        values:
          ofedDriver:
            deploy: true
          rdmaSharedDevicePlugin:
            deploy: true

    - name: Apply NicClusterPolicy
      kubernetes.core.k8s:
        state: present
        src: manifests/nic-cluster-policy.yaml

Final Thoughts

MOFED drivers are not optional for serious GPU infrastructure. If you are running multi-node training workloads on Kubernetes, the network is your bottleneck without RDMA. The Network Operator makes MOFED management Kubernetes-native, and the upgrade policy ensures you can update drivers without downtime. Combined with the GPU Operator, you get a fully automated GPU + networking stack.
