GPUDirect Storage with the NVIDIA GPU Operator

Every GPU training job spends time waiting for data. The traditional path is: storage to CPU memory to GPU memory. GPUDirect Storage (GDS) eliminates the CPU from this path entirely, allowing data to flow directly from storage into GPU memory via DMA. The NVIDIA GPU Operator can deploy and manage the GDS kernel module automatically.

How GPUDirect Storage Works

Without GDS:

NVMe/NFS Storage -> CPU Memory (bounce buffer) -> GPU Memory

With GDS:

NVMe/NFS Storage -> GPU Memory (direct DMA transfer)

The difference is significant:

• 2-3x higher storage throughput to GPU memory
• Reduced CPU utilization (CPU is freed from data movement)
• Lower latency for data loading
• Better GPU utilization (GPUs spend more time computing, less time waiting)

GDS is particularly impactful for:

• Large dataset training (ImageNet, Common Crawl)
• Checkpoint loading and saving
• Model weight loading for inference
• Any workload where I/O is the bottleneck

Prerequisites

• NVIDIA GPU Operator v23.9.0+
• GPUs that support GDS (A100, H100, L40S)
• Compatible storage: local NVMe, NFS over RDMA, Lustre, GPFS/Spectrum Scale, WekaFS
• MOFED drivers installed (for network storage GDS)
• Linux kernel 5.4+

Enabling GDS in the GPU Operator

Via Helm

helm install gpu-operator nvidia/gpu-operator \
  --namespace gpu-operator \
  --create-namespace \
  --set gds.enabled=true \
  --set gds.version="v2.17.5"

Via ClusterPolicy

apiVersion: nvidia.com/v1
kind: ClusterPolicy
metadata:
  name: cluster-policy
spec:
  driver:
    enabled: true
    version: "550.127.05"
  gds:
    enabled: true
    image: nvidia-fs
    repository: nvcr.io/nvidia/cloud-native
    version: "2.17.5"
    imagePullPolicy: IfNotPresent

Verify GDS Installation

# Check GDS driver pod
kubectl get pods -n gpu-operator -l app=nvidia-fs-ctr

# Verify the nvidia-fs kernel module is loaded
kubectl exec -n gpu-operator nvidia-driver-daemonset-xxxx -- lsmod | grep nvidia_fs

# Check GDS status
kubectl exec -n gpu-operator nvidia-driver-daemonset-xxxx -- nvidia-smi -q | grep "GPUDirect"

GDS with Local NVMe Storage

For the highest performance, use local NVMe drives with GDS:

apiVersion: v1
kind: Pod
metadata:
  name: gds-training
spec:
  containers:
    - name: training
      image: nvcr.io/nvidia/pytorch:24.07-py3
      command: ["python", "train.py", "--data-path=/data"]
      resources:
        limits:
          nvidia.com/gpu: 4
      volumeMounts:
        - name: nvme-data
          mountPath: /data
      env:
        - name: CUFILE_ENV_PATH_JSON
          value: "/etc/cufile.json"
  volumes:
    - name: nvme-data
      hostPath:
        path: /mnt/nvme0
        type: Directory

cuFile Configuration

GDS uses the cuFile API. Configure it via cufile.json:

{
  "logging": {
    "type": "stderr",
    "level": "ERROR"
  },
  "profile": {
    "nvtx": false,
    "cufile_stats": 0
  },
  "fs": {
    "generic": {
      "posix_unaligned_writes": false,
      "posix_gds_min_kb": 0
    },
    "lustre": {
      "posix_gds_min_kb": 0
    },
    "beegfs": {
      "posix_gds_min_kb": 0
    }
  },
  "denylist": "",
  "allowlist": ""
}

GDS with Network Storage

For GDS over network storage (NFS, Lustre, GPFS), you need both GDS and MOFED drivers:

helm install gpu-operator nvidia/gpu-operator \
  --namespace gpu-operator \
  --create-namespace \
  --set gds.enabled=true \
  --set driver.rdma.enabled=true \
  --set driver.rdma.useHostMofed=true

This enables the full path: Network Storage -> RDMA NIC -> GPU Memory, bypassing both CPU and system memory.

Benchmarking GDS Performance

Use the gdsio tool to benchmark GDS performance:

# Sequential read benchmark
gdsio -f /data/testfile -d 0 -w 4 -s 1G -i 1M -x 0 -I 1

# Parameters:
# -f: file path
# -d: GPU device ID
# -w: number of workers
# -s: file size
# -i: I/O size
# -x: 0=read, 1=write
# -I: 1=GDS enabled, 0=GDS disabled (for comparison)

Expected results on NVMe with A100:

Using GDS in PyTorch

PyTorch supports GDS through the kvikio library:

import kvikio
import cupy as cp

# Open file with GDS
f = kvikio.CuFile("/data/training_batch.bin", "r")

# Read directly into GPU memory
gpu_buffer = cp.empty(1024 * 1024 * 1024, dtype=cp.uint8)  # 1GB
bytes_read = f.read(gpu_buffer)

# Use in PyTorch
import torch
tensor = torch.as_tensor(gpu_buffer, device='cuda')

For the NVIDIA DALI data loading pipeline, GDS is integrated automatically when the nvidia-fs module is loaded.

GDS with Kubernetes Storage Classes

Integrate GDS with dynamic provisioning:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: nvme-gds
provisioner: kubernetes.io/no-provisioner
volumeBindingMode: WaitForFirstConsumer

---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: nvme-pv
spec:
  capacity:
    storage: 1Ti
  accessModes:
    - ReadWriteOnce
  storageClassName: nvme-gds
  local:
    path: /mnt/nvme0
  nodeAffinity:
    required:
      nodeSelectorTerms:
        - matchExpressions:
            - key: kubernetes.io/hostname
              operator: In
              values: ["gpu-node-1"]

Monitoring GDS

Track GDS usage through DCGM and custom metrics:

# Check GDS statistics
nvidia-smi -q | grep -A 10 "GPU Direct"

# Monitor nvidia-fs module stats
cat /proc/driver/nvidia-fs/stats

Key metrics to monitor:

• GDS reads/writes per second
• GDS throughput (GB/s)
• Fallback to bounce buffer (indicates GDS bypass)
• GPU memory usage for I/O buffers

Automating with Ansible

Deploy GDS across your GPU fleet with Ansible:

---
- name: Enable GPUDirect Storage
  hosts: localhost
  tasks:
    - name: Upgrade GPU Operator with GDS
      kubernetes.core.helm:
        name: gpu-operator
        chart_ref: nvidia/gpu-operator
        release_namespace: gpu-operator
        values:
          gds:
            enabled: true
            version: "2.17.5"
          driver:
            rdma:
              enabled: true
              useHostMofed: true

    - name: Verify GDS on all GPU nodes
      kubernetes.core.k8s_exec:
        namespace: gpu-operator
        pod: "{{ item }}"
        command: lsmod | grep nvidia_fs
      loop: "{{ gpu_driver_pods }}"

Final Thoughts

GPUDirect Storage is one of those optimizations that sounds incremental but delivers transformational results. Doubling your storage-to-GPU throughput while halving CPU utilization means your GPUs spend more time computing and less time waiting. For large-scale training on Kubernetes, enabling GDS through the GPU Operator is a one-line Helm change that pays for itself immediately in GPU utilization improvements.
