Nginx Configuration Cheat Sheet for 2026

A quick reference for Nginx — web server and reverse proxy. Bookmark this page.

Commands

# Start/stop/restart
sudo systemctl start nginx
sudo systemctl stop nginx
sudo systemctl restart nginx
sudo systemctl reload nginx   # Reload config (no downtime)

# Test configuration
sudo nginx -t
sudo nginx -T                 # Test and print full config

# Show version and modules
nginx -v                      # Version
nginx -V                      # Version + compile options

Basic Server Block

server {
    listen 80;
    server_name example.com www.example.com;
    root /var/www/example;
    index index.html;

    location / {
        try_files $uri $uri/ =404;
    }

    location /images/ {
        expires 30d;
        add_header Cache-Control "public, immutable";
    }

    error_page 404 /404.html;
    error_page 500 502 503 504 /50x.html;
}

Reverse Proxy

upstream backend {
    server 10.0.0.1:8080 weight=3;
    server 10.0.0.2:8080;
    server 10.0.0.3:8080 backup;
}

server {
    listen 80;
    server_name api.example.com;

    location / {
        proxy_pass http://backend;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_connect_timeout 5s;
        proxy_read_timeout 30s;
    }
}

HTTPS with Let’s Encrypt

server {
    listen 443 ssl http2;
    server_name example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256;
    ssl_prefer_server_ciphers off;

    add_header Strict-Transport-Security "max-age=63072000" always;
}

server {
    listen 80;
    server_name example.com;
    return 301 https://$server_name$request_uri;
}

Common Patterns

# Rate limiting
limit_req_zone $binary_remote_addr zone=api:10m rate=10r/s;

location /api/ {
    limit_req zone=api burst=20 nodelay;
    proxy_pass http://backend;
}

# Gzip compression
gzip on;
gzip_types text/plain text/css application/json application/javascript text/xml;
gzip_min_length 256;

# Security headers
add_header X-Frame-Options "SAMEORIGIN" always;
add_header X-Content-Type-Options "nosniff" always;
add_header X-XSS-Protection "1; mode=block" always;

# WebSocket proxy
location /ws {
    proxy_pass http://backend;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
}

Tips and Tricks

• Always run nginx -t before reloading to catch syntax errors
• Use reload instead of restart for zero-downtime config changes
• Use try_files $uri $uri/ /index.html for SPA applications
• Use access_log off for static assets to reduce I/O
• Use worker_processes auto to match CPU cores
