Building an ML Platform on Kubernetes

Building an ML platform on Kubernetes means choosing between Kubeflow, MLflow, or a combination of both. Each solves different problems, and most production setups use elements of both.

Kubeflow vs MLflow: Different Tools for Different Problems

Architecture: Kubeflow + MLflow Together

The best ML platform uses both:

┌─────────── ML Platform on Kubernetes ───────────┐
│                                                   │
│  ┌──────────┐  ┌──────────┐  ┌───────────────┐  │
│  │ Jupyter  │  │ Kubeflow │  │ MLflow        │  │
│  │ Notebooks│→ │ Pipelines│→ │ Tracking +    │  │
│  │          │  │ (KFP)    │  │ Model Registry│  │
│  └──────────┘  └──────────┘  └───────────────┘  │
│                      ↓                            │
│              ┌──────────────┐                     │
│              │ KServe       │                     │
│              │ (Model       │                     │
│              │  Serving)    │                     │
│              └──────────────┘                     │
│                                                   │
│  Storage: MinIO (artifacts) + PostgreSQL (metadata)│
└───────────────────────────────────────────────────┘

Kubeflow Setup on Kubernetes

Installation with kustomize

# Clone Kubeflow manifests
git clone https://github.com/kubeflow/manifests.git
cd manifests

# Install (requires kustomize)
while ! kustomize build example | kubectl apply -f -; do
  echo "Retrying..."
  sleep 10
done

Kubeflow Pipeline Example

from kfp import dsl, compiler

@dsl.component(base_image="python:3.11")
def preprocess(data_path: str) -> str:
    import pandas as pd
    df = pd.read_csv(data_path)
    processed = df.dropna().reset_index(drop=True)
    output_path = "/tmp/processed.csv"
    processed.to_csv(output_path, index=False)
    return output_path

@dsl.component(base_image="python:3.11-slim")
def train(data_path: str, model_name: str) -> str:
    import mlflow
    from sklearn.ensemble import RandomForestClassifier

    mlflow.set_tracking_uri("http://mlflow-server:5000")
    with mlflow.start_run():
        # Train model
        model = RandomForestClassifier(n_estimators=100)
        # ... training code ...
        mlflow.sklearn.log_model(model, model_name)
    return model_name

@dsl.pipeline(name="ml-training-pipeline")
def training_pipeline(data_path: str = "s3://data/train.csv"):
    preprocess_task = preprocess(data_path=data_path)
    train_task = train(
        data_path=preprocess_task.output,
        model_name="fraud-detector"
    )

compiler.Compiler().compile(training_pipeline, "pipeline.yaml")

MLflow Setup on Kubernetes

apiVersion: apps/v1
kind: Deployment
metadata:
  name: mlflow-server
spec:
  replicas: 1
  selector:
    matchLabels:
      app: mlflow
  template:
    metadata:
      labels:
        app: mlflow
    spec:
      containers:
        - name: mlflow
          image: ghcr.io/mlflow/mlflow:2.14.0
          command: ["mlflow", "server"]
          args:
            - "--backend-store-uri=postgresql://mlflow:password@postgres:5432/mlflow"
            - "--default-artifact-root=s3://mlflow-artifacts/"
            - "--host=0.0.0.0"
            - "--port=5000"
          ports:
            - containerPort: 5000
          env:
            - name: AWS_ACCESS_KEY_ID
              valueFrom:
                secretKeyRef:
                  name: minio-credentials
                  key: access-key

Model Serving with KServe

apiVersion: serving.kserve.io/v1beta1
kind: InferenceService
metadata:
  name: fraud-detector
spec:
  predictor:
    model:
      modelFormat:
        name: mlflow
      storageUri: "s3://mlflow-artifacts/fraud-detector/latest"
      resources:
        limits:
          nvidia.com/gpu: 1

Production Checklist

• Centralized experiment tracking (MLflow)
• Reproducible pipelines (Kubeflow Pipelines)
• Model versioning and registry
• A/B testing infrastructure for model comparison
• GPU scheduling and resource quotas
• Data versioning (DVC or LakeFS)
• Monitoring for model drift
• Automated retraining triggers
