Enable PFC on Mellanox ConnectX NICs for

Why Priority Flow Control Matters

Priority Flow Control (PFC) is a Layer 2 mechanism (IEEE 802.1Qbb) that prevents packet loss on specific traffic classes by sending pause frames when buffer thresholds are reached. Without PFC, Ethernet is a lossy fabric — packets get dropped when buffers overflow, and upper-layer protocols must retransmit.

For most workloads, TCP retransmission handles this transparently. But for RDMA over Converged Ethernet (RoCEv2), packet loss is catastrophic. RDMA bypasses the kernel networking stack entirely — there is no TCP to save you. A single dropped packet can stall an entire RDMA queue pair, killing throughput for GPU-to-GPU communication in AI training clusters.

Bottom line: if you are running RoCEv2 for AI training, distributed inference, or HPC, you need PFC enabled on both the NIC and the switch. No exceptions.

Prerequisites

• NVIDIA/Mellanox ConnectX-4 or later (ConnectX-5, ConnectX-6, ConnectX-7)
• MLNX_OFED drivers installed (or inbox drivers with mlnx_qos available)
• Managed switch that supports PFC (Mellanox Spectrum, Cisco Nexus, Arista, etc.)
• Root access on the host

Verify your NIC and driver:

# Check NIC model
lspci | grep Mellanox

# Check driver version
ethtool -i ens1f0 | grep -E "driver|version"

# Verify OFED installation
ofed_info -s

Step 1: Identify Your Interfaces

# List Mellanox interfaces
ibdev2netdev
# Output example:
# mlx5_0 port 1 ==> ens1f0 (Up)
# mlx5_1 port 1 ==> ens1f1 (Up)

# Or use rdma tool
rdma link show

For the rest of this guide, we will use ens1f0 as the interface. Replace with your actual interface name.

Step 2: Enable DCBX and PFC with mlnx_qos

mlnx_qos is the primary tool for configuring Data Center Bridging (DCB) parameters on Mellanox NICs.

Check Current PFC Status

mlnx_qos -i ens1f0

You will see output like:

Priority trust state: pcp
PFC configuration:
        priority    0   1   2   3   4   5   6   7
        enabled     0   0   0   0   0   0   0   0

All priorities are disabled by default. You need to enable PFC on the priority that carries your RoCEv2 traffic.

Enable PFC on Priority 3 (Default RoCEv2)

By convention, RoCEv2 traffic uses priority 3 (or priority 4 in some configurations). Check your switch configuration to confirm which priority your DSCP/PCP mapping uses.

# Enable PFC on priority 3
mlnx_qos -i ens1f0 --pfc 0,0,0,1,0,0,0,0

Verify:

mlnx_qos -i ens1f0
# PFC configuration:
#         priority    0   1   2   3   4   5   6   7
#         enabled     0   0   0   1   0   0   0   0

Set Trust Mode to DSCP

For RoCEv2, you want the NIC to classify traffic based on DSCP values in the IP header, not PCP tags in the VLAN header. This is critical — if trust mode is set to PCP but your traffic is untagged, PFC will never trigger.

# Set trust mode to DSCP
mlnx_qos -i ens1f0 --trust dscp

Verify:

mlnx_qos -i ens1f0 | grep trust
# Priority trust state: dscp

Map DSCP to Traffic Class and Priority

RoCEv2 uses DSCP 26 (AF31) by default. Map it to traffic class 3 and priority 3:

# Map DSCP 26 to traffic class 3
mlnx_qos -i ens1f0 --dscp2prio set,26,3

Verify the mapping:

mlnx_qos -i ens1f0 --dscp2prio show

Step 3: Configure Traffic Classes

Allocate bandwidth across traffic classes. You want to guarantee bandwidth for your RoCEv2 traffic class while allowing best-effort traffic on the remaining classes.

# Configure 8 traffic classes
# TC 0-2: best effort (shared)
# TC 3: RoCEv2 (strict priority or guaranteed bandwidth)
# TC 4-7: best effort (shared)

mlnx_qos -i ens1f0 \
  --tc_bw 12,12,12,52,3,3,3,3 \
  --tsa ets,ets,ets,ets,ets,ets,ets,ets

This gives TC 3 (RoCEv2) 52% of bandwidth, with the rest distributed across other traffic classes.

For strict priority (RoCEv2 always gets served first):

mlnx_qos -i ens1f0 \
  --tc_bw 12,12,12,52,3,3,3,3 \
  --tsa ets,ets,ets,strict,ets,ets,ets,ets

Step 4: Configure PFC via lldptool (Alternative Method)

If you are using DCBX negotiation with your switch, lldptool configures PFC through LLDP/DCBX protocol exchange:

# Enable DCBX on the interface
lldptool -T -i ens1f0 -V CEE-DCBX enableTx=yes
lldptool -T -i ens1f0 -V IEEE-DCBX enableTx=yes

# Enable PFC on priority 3
lldptool -T -i ens1f0 -V PFC enabled=3

# Verify PFC status
lldptool -t -i ens1f0 -V PFC

Note: mlnx_qos and lldptool can conflict. Use one method consistently. For most AI clusters, mlnx_qos with manual configuration is preferred over DCBX negotiation.

Step 5: Switch-Side Configuration

PFC must be enabled on both ends — the NIC and the switch port. Here are examples for common switch platforms:

Mellanox/NVIDIA Spectrum (Cumulus/NVOS)

# /etc/cumulus/datapath/qos/qos_features.conf
pfc.port_group.roce.pfc_enable = 3
pfc.port_group.roce.port_set = swp1-48
pfc.port_group.roce.cos_list = [3]
pfc.port_group.roce.buffer_size = 100000

# Apply
sudo systemctl restart switchd

Cisco Nexus

! Enable PFC on priority 3
interface Ethernet1/1
  priority-flow-control mode on
  priority-flow-control priority 3 no-drop

! QoS policy
policy-map type qos roce-qos
  class class-default
    set qos-group 0
  class roce-traffic
    set qos-group 3

policy-map type queuing roce-queuing
  class type queuing c-out-8q-q3
    priority level 1
    no-drop

Arista EOS

! QoS map
qos map dscp 26 traffic-class 3

! PFC on priority 3
interface Ethernet1
  priority-flow-control priority 3 no-drop
  priority-flow-control on

Step 6: Verify PFC Is Working

Check PFC Counters

# PFC pause frames sent/received
ethtool -S ens1f0 | grep pfc
# rx_pfc_pause_0: 0
# rx_pfc_pause_1: 0
# rx_pfc_pause_2: 0
# rx_pfc_pause_3: 1247    <-- PFC frames received on priority 3
# tx_pfc_pause_0: 0
# tx_pfc_pause_3: 892     <-- PFC frames sent on priority 3

Non-zero counters on priority 3 confirm PFC is active and working.

Check for PFC Storms

PFC storms occur when a host continuously sends pause frames, stalling the entire priority class across the fabric. Monitor for anomalies:

# Watch PFC counters in real-time
watch -n 1 "ethtool -S ens1f0 | grep pfc"

If tx_pfc_pause_3 increments continuously without traffic, you have a PFC storm. Common causes:

• Misconfigured buffer sizes
• Slow receiver (host under memory pressure)
• NIC firmware bug

Verify RoCEv2 Is Using the Correct Priority

# Check RDMA counters
rdma statistic show link mlx5_0/1

# Run a quick RDMA bandwidth test
ib_write_bw -d mlx5_0 -x 3  # on server
ib_write_bw -d mlx5_0 -x 3 <server_ip>  # on client

Step 7: Make Configuration Persistent

mlnx_qos settings are not persistent across reboots by default. You need to persist them.

Option A: NetworkManager Dispatcher Script

cat > /etc/NetworkManager/dispatcher.d/99-pfc-config << 'EOF'
#!/bin/bash
IFACE=$1
ACTION=$2

if [ "$ACTION" = "up" ] && [ "$IFACE" = "ens1f0" ]; then
    mlnx_qos -i ens1f0 --pfc 0,0,0,1,0,0,0,0
    mlnx_qos -i ens1f0 --trust dscp
    mlnx_qos -i ens1f0 --dscp2prio set,26,3
    mlnx_qos -i ens1f0 --tc_bw 12,12,12,52,3,3,3,3 \
      --tsa ets,ets,ets,ets,ets,ets,ets,ets
fi
EOF
chmod +x /etc/NetworkManager/dispatcher.d/99-pfc-config

Option B: systemd Service

cat > /etc/systemd/system/pfc-config.service << 'EOF'
[Unit]
Description=Configure PFC on Mellanox NICs
After=network-online.target
Wants=network-online.target

[Service]
Type=oneshot
RemainAfterExit=yes
ExecStart=/usr/bin/mlnx_qos -i ens1f0 --pfc 0,0,0,1,0,0,0,0
ExecStart=/usr/bin/mlnx_qos -i ens1f0 --trust dscp
ExecStart=/usr/bin/mlnx_qos -i ens1f0 --dscp2prio set,26,3

[Install]
WantedBy=multi-user.target
EOF

systemctl daemon-reload
systemctl enable pfc-config.service

Option C: Ansible (Recommended for Clusters)

- name: Configure PFC on Mellanox NICs
  hosts: gpu_nodes
  become: true
  tasks:
    - name: Enable PFC on priority 3
      command: mlnx_qos -i {{ rdma_interface }} --pfc 0,0,0,1,0,0,0,0

    - name: Set trust mode to DSCP
      command: mlnx_qos -i {{ rdma_interface }} --trust dscp

    - name: Map DSCP 26 to priority 3
      command: mlnx_qos -i {{ rdma_interface }} --dscp2prio set,26,3

    - name: Configure traffic class bandwidth
      command: >
        mlnx_qos -i {{ rdma_interface }}
        --tc_bw 12,12,12,52,3,3,3,3
        --tsa ets,ets,ets,ets,ets,ets,ets,ets

Troubleshooting

PFC Not Triggering

# Verify trust mode is DSCP
mlnx_qos -i ens1f0 | grep trust
# Must show: dscp (not pcp)

# Verify DSCP mapping
mlnx_qos -i ens1f0 --dscp2prio show
# DSCP 26 must map to priority 3

# Verify switch port has PFC enabled on same priority
# (check switch-side config)

# Check if DCBX is overriding manual settings
lldptool -t -i ens1f0 -V PFC
# If DCBX is negotiating different values, disable it:
mlnx_qos -i ens1f0 --dcbx_mode=0

High PFC Pause Frame Count

# Check buffer allocation
mlnx_qos -i ens1f0 --buffer_size

# Check for headroom issues
ethtool -S ens1f0 | grep -E "rx_buffer|headroom"

# Increase buffer for priority 3 if needed
# (switch-side, varies by platform)

RDMA Performance Degradation

# Check for ECN (Explicit Congestion Notification) conflicts
sysctl net.ipv4.tcp_ecn

# Verify RDMA CM (Connection Manager) is using correct GID
ibv_devinfo -d mlx5_0 -v | grep GID

# Check for competing traffic on same priority
mlnx_qos -i ens1f0  # verify TC bandwidth allocation

PFC vs ECN: When to Use Each

Best practice: Use both PFC and ECN together. PFC is the safety net that prevents drops. ECN with DCQCN (Data Center Quantized Congestion Notification) is the congestion signal that reduces PFC events. In a well-tuned fabric, you should see very few PFC pause frames because ECN handles congestion before buffers overflow.

Quick Reference: Complete Setup

# 1. Enable PFC on priority 3
mlnx_qos -i ens1f0 --pfc 0,0,0,1,0,0,0,0

# 2. Set trust mode to DSCP
mlnx_qos -i ens1f0 --trust dscp

# 3. Map DSCP 26 (AF31) to priority 3
mlnx_qos -i ens1f0 --dscp2prio set,26,3

# 4. Allocate bandwidth (52% to RoCEv2)
mlnx_qos -i ens1f0 --tc_bw 12,12,12,52,3,3,3,3 \
  --tsa ets,ets,ets,ets,ets,ets,ets,ets

# 5. Verify
mlnx_qos -i ens1f0
ethtool -S ens1f0 | grep pfc

# 6. Test RDMA
ib_write_bw -d mlx5_0 -x 3

Configure the same priority on your switch ports, and you have lossless RDMA networking.
