Keycloak: Enterprise Identity and Access Management on Kubernetes

What Is Keycloak?

Keycloak provides SSO, identity federation, and fine-grained authorization for applications. CNCF project (donated by Red Hat). Supports OIDC, SAML 2.0, OAuth 2.0, and LDAP/AD integration.

Core Capabilities

• Single Sign-On (SSO) — one login for all applications
• Identity Federation — connect Google, GitHub, LDAP, SAML IdPs
• Fine-grained RBAC — roles, groups, client scopes
• Multi-tenancy — isolated realms per tenant/environment
• Admin console — full web UI for user/role management
• Token exchange — impersonation, cross-realm trust

Kubernetes Deployment

apiVersion: k8s.keycloak.org/v2alpha1
kind: Keycloak
metadata:
  name: keycloak
  namespace: keycloak
spec:
  instances: 3
  hostname:
    hostname: auth.yourdomain.com
  db:
    vendor: postgres
    host: postgres.keycloak.svc
    usernameSecret:
      name: keycloak-db
      key: username
    passwordSecret:
      name: keycloak-db
      key: password
  http:
    tlsSecret: keycloak-tls
  features:
    enabled:
      - docker
      - token-exchange

Integrate with Kubernetes OIDC

# kube-apiserver flags
--oidc-issuer-url=https://auth.yourdomain.com/realms/kubernetes
--oidc-client-id=kubernetes
--oidc-username-claim=preferred_username
--oidc-groups-claim=groups

Now kubectl uses Keycloak tokens:

# kubelogin plugin
kubectl oidc-login setup \
  --oidc-issuer-url=https://auth.yourdomain.com/realms/kubernetes \
  --oidc-client-id=kubernetes

Integrate with ArgoCD

# argocd-cm ConfigMap
data:
  oidc.config: |
    name: Keycloak
    issuer: https://auth.yourdomain.com/realms/argocd
    clientID: argocd
    clientSecret: $oidc.keycloak.clientSecret
    requestedScopes: ["openid", "profile", "email", "groups"]

Integrate with Grafana

[auth.generic_oauth]
enabled = true
name = Keycloak
client_id = grafana
client_secret = xxx
auth_url = https://auth.yourdomain.com/realms/monitoring/protocol/openid-connect/auth
token_url = https://auth.yourdomain.com/realms/monitoring/protocol/openid-connect/token
api_url = https://auth.yourdomain.com/realms/monitoring/protocol/openid-connect/userinfo
role_attribute_path = contains(groups[*], 'grafana-admin') && 'Admin' || 'Viewer'

High Availability

┌─────────────────────────────────────────┐
│           Load Balancer                  │
└──────┬──────────┬──────────┬────────────┘
       │          │          │
┌──────▼──┐ ┌────▼────┐ ┌───▼──────┐
│Keycloak │ │Keycloak │ │Keycloak  │
│ Pod 1   │ │ Pod 2   │ │ Pod 3    │
└────┬────┘ └────┬────┘ └────┬─────┘
     │           │            │
     └───────────┼────────────┘
                 │
        ┌────────▼────────┐
        │   PostgreSQL    │
        │   (HA cluster)  │
        └─────────────────┘

Keycloak uses Infinispan distributed cache — sessions shared across all pods. Zero-downtime rolling updates.

Security Hardening

# Realm settings for production
bruteForceDetection:
  enabled: true
  maxFailureWaitSeconds: 900
  maxLoginFailures: 5
  waitIncrementSeconds: 60
passwordPolicy: "length(12) and upperCase(1) and digit(1) and specialChars(1)"
sslRequired: "all"
loginWithEmail: false
duplicateEmailsAllowed: false
