GPU Sharing on Kubernetes: MIG vs MPS vs Time-Slicing

Why Share GPUs?

A single A100 80GB costs $3.25/hour. Many AI workloads don’t need a full GPU:

• Development/testing — needs 10-20% of an A100
• Small model inference — 7B models use 16GB of 80GB
• Batch preprocessing — CPU-bound with occasional GPU burst
• Multiple small models — each needs 10-20GB

Without sharing, you waste 60-80% of GPU capacity. Three technologies solve this:

Comparison Matrix

Multi-Instance GPU (MIG)

MIG hardware-partitions a GPU into up to 7 isolated instances. Each instance has dedicated compute, memory, and cache — like separate physical GPUs.

Supported GPU Profiles (A100 80GB)

Enable MIG on Kubernetes

# GPU Operator configuration
apiVersion: v1
kind: ConfigMap
metadata:
  name: gpu-operator-mig-config
  namespace: gpu-operator
data:
  config.yaml: |
    version: v1
    mig-configs:
      all-1g.10gb:
        - device-filter: ["0x20B210DE"]  # A100
          devices: all
          mig-enabled: true
          mig-devices:
            "1g.10gb": 7
      mixed:
        - device-filter: ["0x20B210DE"]
          devices: all
          mig-enabled: true
          mig-devices:
            "3g.40gb": 1
            "2g.20gb": 1
            "1g.10gb": 2

Request MIG Slices in Pods

apiVersion: v1
kind: Pod
metadata:
  name: inference-small
spec:
  containers:
    - name: model
      image: vllm/vllm-openai:latest
      resources:
        limits:
          nvidia.com/mig-1g.10gb: 1  # Request 1 MIG slice (10GB)
---
apiVersion: v1
kind: Pod
metadata:
  name: inference-large
spec:
  containers:
    - name: model
      resources:
        limits:
          nvidia.com/mig-3g.40gb: 1  # Request larger slice (40GB)

MIG Best Practices

• Use 1g.10gb for 7B models (Llama 8B fits in quantized form)
• Use 3g.40gb for 13-34B models
• Use 7g.80gb (full GPU) for 70B+ models
• Cannot mix MIG profiles on same GPU — plan ahead
• Reconfiguring MIG requires GPU reset (brief downtime)

Multi-Process Service (MPS)

MPS allows multiple CUDA processes to share a GPU simultaneously via a shared CUDA context. No hardware partitioning — processes cooperatively share compute.

How MPS Works

Without MPS:              With MPS:
┌─────────────┐           ┌─────────────┐
│   Process A │ ──time──▶ │ Process A+B │ ──parallel──▶
│   Process B │   slice   │  (shared)   │   execution
└─────────────┘           └─────────────┘
     GPU idle               GPU busy
   between procs           continuously

Enable MPS on Kubernetes

# NVIDIA device plugin config
apiVersion: v1
kind: ConfigMap
metadata:
  name: nvidia-device-plugin
data:
  config.yaml: |
    version: v1
    sharing:
      mps:
        renameByDefault: false
        resources:
          - name: nvidia.com/gpu
            replicas: 10  # Allow 10 pods to share each GPU

Request Shared GPU

apiVersion: v1
kind: Pod
metadata:
  name: preprocessing
spec:
  containers:
    - name: worker
      resources:
        limits:
          nvidia.com/gpu: 1  # Gets shared access via MPS
        requests:
          nvidia.com/gpu: 1

MPS Limitations

• No memory isolation — one process can OOM and crash all
• No fault isolation — CUDA error affects all processes
• Best for cooperative workloads you control (same team, same app)
• Not recommended for multi-tenant production environments

Time-Slicing

The simplest approach: multiple pods take turns using the GPU. The NVIDIA device plugin advertises more GPUs than physically exist.

Configure Time-Slicing

apiVersion: v1
kind: ConfigMap
metadata:
  name: nvidia-device-plugin
data:
  config.yaml: |
    version: v1
    sharing:
      timeSlicing:
        renameByDefault: false
        resources:
          - name: nvidia.com/gpu
            replicas: 4  # Each GPU appears as 4 virtual GPUs

How It Works

• GPU rapidly switches between processes (context switching)
• Each pod “sees” a full GPU but shares time
• No memory isolation — total memory is shared
• ~10-15% overhead from context switching

Best For

• Development clusters — many developers sharing few GPUs
• CI/CD pipelines — short GPU jobs that don’t need full capacity
• Non-critical workloads — where occasional latency spikes are acceptable

Decision Framework

Choose MIG when:

• ✅ Production multi-tenant GPU sharing
• ✅ Need guaranteed memory and compute isolation
• ✅ Running different customers/teams on same hardware
• ✅ Using A100/H100/H200 GPUs
• ✅ Security requirements demand isolation

Choose MPS when:

• ✅ Multiple cooperative processes from same application
• ✅ Batch inference with many small models
• ✅ Need higher GPU utilization without hardware partitioning
• ✅ Processes are trusted (same team/namespace)
• ✅ Using older GPUs without MIG support (V100, T4)

Choose Time-Slicing when:

• ✅ Development and testing environments
• ✅ CI/CD GPU access for unit tests
• ✅ Budget constraints (any GPU works)
• ✅ Workloads are bursty (idle most of the time)
• ✅ Simplicity over performance

Cost Savings Example

Scenario: 4 teams each running a 7B model inference service

All three save 75% — but MIG gives production-grade isolation at the same cost.
