GPU Cluster Architecture: Designing for Both Training and

Training and inference have different resource profiles. Design GPU clusters that handle both workloads efficiently with dynamic partitioning.

Luca Berton

Β· The Production AI Expert

Published Β·2 min read

GPU clusters for AI workloads come in two fundamentally different architectures: training clusters optimized for throughput and collective communication, and inference clusters optimized for latency and cost efficiency. Getting this wrong wastes hundreds of thousands of dollars.

Training vs Inference: Different Requirements

DimensionTraining ClusterInference Cluster
PriorityThroughput (tokens/second)Latency (ms per request)
GPU utilization target95%+ sustained50-70% (headroom for bursts)
NetworkInfiniBand 400Gbps (RDMA)Standard 100GbE sufficient
StorageHigh-throughput parallel FSFast model loading, minimal storage
Batch sizeLarge (thousands)Small (1-64)
Scaling patternAll GPUs active simultaneouslyScale up/down with demand
Cost model$/training run$/1000 tokens served
Failure toleranceCheckpoint and resumeRedundancy and failover

Training Cluster Architecture

Network Topology

Training clusters need all-reduce communication across all GPUs. The network is the bottleneck:

β”Œβ”€β”€β”€β”€ Spine Switch (InfiniBand 400G) ────┐
β”‚                                         β”‚
β”œβ”€β”€β”€ Leaf ────  β”œβ”€β”€β”€ Leaf ────  β”œβ”€β”€β”€ Leaf ────
β”‚   Switch   β”‚  β”‚   Switch   β”‚  β”‚   Switch   β”‚
β”‚            β”‚  β”‚            β”‚  β”‚            β”‚
β”‚ β”Œβ”€β”€β” β”Œβ”€β”€β” β”‚  β”‚ β”Œβ”€β”€β” β”Œβ”€β”€β” β”‚  β”‚ β”Œβ”€β”€β” β”Œβ”€β”€β” β”‚
β”‚ β”‚N1β”‚ β”‚N2β”‚ β”‚  β”‚ β”‚N3β”‚ β”‚N4β”‚ β”‚  β”‚ β”‚N5β”‚ β”‚N6β”‚ β”‚
β”‚ β”‚8Gβ”‚ β”‚8Gβ”‚ β”‚  β”‚ β”‚8Gβ”‚ β”‚8Gβ”‚ β”‚  β”‚ β”‚8Gβ”‚ β”‚8Gβ”‚ β”‚
β”‚ β””β”€β”€β”˜ β””β”€β”€β”˜ β”‚  β”‚ β””β”€β”€β”˜ β””β”€β”€β”˜ β”‚  β”‚ β””β”€β”€β”˜ β””β”€β”€β”˜ β”‚
β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜  β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜  β””β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”€β”˜
         48 GPUs total (6 nodes Γ— 8 GPUs)

Storage Architecture

Training data needs high-throughput parallel access:

  • GPFS/Lustre/WekaFS: Parallel filesystem for dataset access
  • Throughput target: 100+ GB/s aggregate read for large clusters
  • NVMe cache: Local NVMe on each node for checkpoint writes
  • Object storage: S3/MinIO for long-term dataset and checkpoint storage

NCCL Configuration

# Essential NCCL environment variables for training clusters
export NCCL_IB_HCA=mlx5_0,mlx5_1    # InfiniBand adapters
export NCCL_SOCKET_IFNAME=eth0        # Fallback interface
export NCCL_DEBUG=INFO                # Debugging
export NCCL_TIMEOUT=1800              # 30 min timeout for large all-reduce
export NCCL_ALGO=Ring                 # or Tree for different topologies
export NCCL_PROTO=Simple              # or LL128 for low latency

Inference Cluster Architecture

Autoscaling Architecture

Inference clusters must scale with demand:

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: inference-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: llm-inference
  minReplicas: 2
  maxReplicas: 20
  metrics:
    - type: Pods
      pods:
        metric:
          name: inference_queue_depth
        target:
          type: AverageValue
          averageValue: "5"  # Scale when queue > 5 per pod

Multi-Model Serving

Run multiple models on shared GPU infrastructure:

  • Time-slicing: Multiple models share one GPU via time division
  • MIG (Multi-Instance GPU): Hardware partitioning on A100/H100
  • MPS (Multi-Process Service): Concurrent model execution
  • KV-cache sharing: Models share KV-cache across requests (vLLM, NVIDIA Dynamo)

Cost Optimization

Inference cost optimization strategies:

  1. Right-size GPUs: Use L4 for small models, A100 for medium, H100 for large
  2. Quantization: INT8/INT4 reduces GPU memory and increases throughput 2-4x
  3. Batching: Dynamic batching increases GPU utilization significantly
  4. Spot/preemptible instances: Use for non-latency-sensitive batch inference
  5. Model routing: Route simple queries to smaller/cheaper models

Hybrid Cluster Design

Some organizations run both training and inference on shared infrastructure:

  • Partition by time: Training at night (cheap electricity), inference during business hours
  • Partition by node: Dedicated training nodes (InfiniBand) + inference nodes (Ethernet)
  • Partition by GPU: MIG slices for inference on some GPUs, full GPUs for training

Sizing Guide

Training Cluster Sizing

GPUs needed = Model Parameters / (GPU Memory Γ— Parallelism Efficiency)

Example: Training a 70B model
  - Model: 70B parameters Γ— 4 bytes (FP32) = 280 GB
  - With mixed precision: ~140 GB
  - Per H100 (80GB): Need at least 2 GPUs for model weights
  - With optimizer states: 4-8Γ— model size = 560 GB - 1.1 TB
  - Minimum: 8Γ— H100 (one node)
  - For reasonable training time: 32-64Γ— H100

Inference Cluster Sizing

GPUs needed = (Peak QPS Γ— Latency Target) / Throughput per GPU

Example: Serving a 70B model
  - Target: 100 QPS, under 2s latency
  - Per H100 with vLLM: ~30 QPS at 2s latency
  - GPUs needed: ceil(100/30) = 4 GPUs
  - With redundancy (N+1): 5 GPUs
  - Plus 50% headroom for burst: 8 GPUs (1 node)
