Disaster Recovery for Kubernetes: Enterprise

“We have Velero backups” is not a disaster recovery plan. DR means you can recover your entire platform to a defined state within a defined time, and you have tested it.

DR Patterns

Pattern 1: Active-Passive

Region A (Active)           Region B (Passive)
┌──────────────┐           ┌──────────────┐
│ Production   │  Velero   │ Standby      │
│ Cluster      │──backup──▶│ Cluster      │
│ Traffic: 100%│  hourly   │ Traffic: 0%  │
│              │           │ Scaled down  │
└──────────────┘           └──────────────┘
      │                          │
      └────── Global LB ────────┘
              (DNS failover)

RTO: 15-60 minutes (scale up standby + restore state) RPO: 1 hour (backup frequency) Cost: ~30% of production (standby runs minimal resources)

Pattern 2: Active-Active

Region A                    Region B
┌──────────────┐           ┌──────────────┐
│ Production   │◀── sync ─▶│ Production   │
│ Cluster      │           │ Cluster      │
│ Traffic: 50% │           │ Traffic: 50% │
└──────────────┘           └──────────────┘
      │                          │
      └────── Global LB ────────┘
              (weighted routing)

RTO: under 1 minute (traffic shifts automatically) RPO: Near-zero (synchronous or near-synchronous replication) Cost: ~100% of production (both regions run full capacity)

Pattern 3: Pilot Light

Region A (Active)           Region B (Pilot Light)
┌──────────────┐           ┌──────────────┐
│ Production   │  ArgoCD   │ Control plane│
│ Full stack   │──sync────▶│ running      │
│ Traffic: 100%│           │ No workers   │
│              │           │ Data synced  │
└──────────────┘           └──────────────┘

RTO: 5-15 minutes (add worker nodes via Cluster API/Karpenter) RPO: Minutes (continuous data replication) Cost: ~10-15% of production (control plane + storage only)

Velero Backup Strategy

# Scheduled backup for production namespace
apiVersion: velero.io/v1
kind: Schedule
metadata:
  name: production-hourly
spec:
  schedule: "0 * * * *"
  template:
    includedNamespaces:
      - production
      - monitoring
      - ingress-system
    includedResources:
      - deployments
      - services
      - configmaps
      - secrets
      - persistentvolumeclaims
    storageLocation: s3-cross-region
    volumeSnapshotLocations:
      - ebs-cross-region
    ttl: 720h  # 30 days retention

DR Runbook Template

# Disaster Recovery Runbook: Region A Failure

## Trigger Criteria
- Region A unreachable for > 5 minutes
- Multiple service health checks failing
- Cloud provider status page confirms outage

## Step 1: Confirm Outage (2 minutes)
- [ ] Verify from multiple monitoring points
- [ ] Check cloud provider status page
- [ ] Notify incident commander

## Step 2: Activate DR (5 minutes)
- [ ] Scale up Region B worker nodes: `kubectl scale ...`
- [ ] Restore latest Velero backup: `velero restore create ...`
- [ ] Verify pods are running: `kubectl get pods -A`

## Step 3: Switch Traffic (2 minutes)
- [ ] Update DNS/Global LB to route to Region B
- [ ] Verify traffic is flowing to Region B
- [ ] Monitor error rates for 5 minutes

## Step 4: Communicate
- [ ] Notify stakeholders: "Failover complete, RTO: X minutes"
- [ ] Update status page

## Rollback (when Region A recovers)
- [ ] Sync data from Region B back to Region A
- [ ] Gradually shift traffic back (10% → 50% → 100%)
- [ ] Scale down Region B to standby

Testing DR

If you have not tested it, it does not work. Schedule quarterly DR tests:

1. Tabletop exercise — walk through the runbook verbally
2. Component test — restore a single namespace from backup
3. Full failover test — simulate region failure, execute full runbook
4. Chaos engineering — inject failures randomly (Chaos Mesh, Litmus)
