Edge AI Monitoring with Prometheus and Grafana: Fleet Observability

You Can’t Improve What You Can’t Measure

An edge AI model in production without monitoring is a ticking time bomb. Models drift. Hardware degrades. Cameras get dirty. You need to know when performance drops — before the business does.

The Metrics That Matter

Inference Metrics

from prometheus_client import Histogram, Counter, Gauge, start_http_server

# Core inference metrics
INFERENCE_LATENCY = Histogram(
    'inference_latency_seconds',
    'Inference latency in seconds',
    buckets=[0.005, 0.01, 0.015, 0.02, 0.05, 0.1, 0.5]
)

INFERENCE_COUNT = Counter(
    'inference_total',
    'Total inferences processed',
    ['model_version', 'result']
)

CONFIDENCE_SCORE = Histogram(
    'prediction_confidence',
    'Model confidence scores',
    buckets=[0.1, 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 0.95, 0.99]
)

MODEL_VERSION = Gauge(
    'model_version_info',
    'Currently loaded model version',
    ['version']
)

# Usage in inference loop
@INFERENCE_LATENCY.time()
def run_inference(image):
    prediction = model.predict(image)
    INFERENCE_COUNT.labels(
        model_version='3.2',
        result=prediction.label
    ).inc()
    CONFIDENCE_SCORE.observe(prediction.confidence)
    return prediction

# Expose metrics on :9090/metrics
start_http_server(9090)

Hardware Metrics

import subprocess
import json

GPU_TEMP = Gauge('gpu_temperature_celsius', 'GPU temperature')
GPU_UTIL = Gauge('gpu_utilization_percent', 'GPU utilization')
MEMORY_USED = Gauge('gpu_memory_used_bytes', 'GPU memory used')

def collect_jetson_metrics():
    """Collect Jetson hardware metrics via tegrastats."""
    stats = subprocess.check_output(['tegrastats', '--interval', '1000', '--count', '1'])
    # Parse tegrastats output
    gpu_temp = parse_temp(stats)
    gpu_util = parse_util(stats)
    mem_used = parse_memory(stats)

    GPU_TEMP.set(gpu_temp)
    GPU_UTIL.set(gpu_util)
    MEMORY_USED.set(mem_used)

Data Quality Metrics

IMAGE_BRIGHTNESS = Histogram(
    'input_image_brightness',
    'Average brightness of input images',
    buckets=[20, 40, 60, 80, 100, 120, 140, 160, 180, 200]
)

IMAGE_BLUR = Histogram(
    'input_image_blur_score',
    'Laplacian variance (blur detection)',
    buckets=[10, 50, 100, 200, 500, 1000]
)

def check_image_quality(image):
    brightness = image.mean()
    blur = cv2.Laplacian(image, cv2.CV_64F).var()

    IMAGE_BRIGHTNESS.observe(brightness)
    IMAGE_BLUR.observe(blur)

    if brightness < 30:
        alert("Camera may be obstructed or lighting failed")
    if blur < 50:
        alert("Camera may be out of focus")

Prometheus Configuration

# prometheus.yml - Central Prometheus scraping edge devices
global:
  scrape_interval: 30s
  evaluation_interval: 30s

scrape_configs:
  - job_name: 'edge-ai-fleet'
    file_sd_configs:
      - files:
          - /etc/prometheus/edge_targets/*.json
        refresh_interval: 5m

  # Or use DNS service discovery if devices register
  - job_name: 'edge-ai-dns'
    dns_sd_configs:
      - names:
          - '_metrics._tcp.edge.internal'
        type: SRV
        refresh_interval: 60s

# Alert rules
rule_files:
  - /etc/prometheus/rules/edge_ai_alerts.yml

Alert Rules

# edge_ai_alerts.yml
groups:
  - name: edge_ai
    rules:
      - alert: HighInferenceLatency
        expr: histogram_quantile(0.95, rate(inference_latency_seconds_bucket[5m])) > 0.05
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High inference latency on {{ $labels.instance }}"
          description: "P95 latency is {{ $value }}s (threshold: 50ms)"

      - alert: LowConfidenceSpike
        expr: rate(prediction_confidence_bucket{le="0.5"}[15m]) / rate(prediction_confidence_count[15m]) > 0.1
        for: 10m
        labels:
          severity: critical
        annotations:
          summary: "Model confidence dropping on {{ $labels.instance }}"
          description: ">10% of predictions below 0.5 confidence — possible model drift"

      - alert: GPUOverheating
        expr: gpu_temperature_celsius > 85
        for: 2m
        labels:
          severity: critical
        annotations:
          summary: "GPU overheating on {{ $labels.instance }}"

      - alert: DeviceUnreachable
        expr: up{job="edge-ai-fleet"} == 0
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "Edge device {{ $labels.instance }} unreachable"

Model Accuracy Drift Detection

The most insidious edge AI failure: the model slowly gets worse. New product variants, lighting changes, seasonal differences.

# Track accuracy against known-good reference images
VALIDATION_ACCURACY = Gauge(
    'model_validation_accuracy',
    'Accuracy on reference validation set'
)

def periodic_validation():
    """Run every hour against reference images."""
    correct = 0
    total = 0
    for image, expected in REFERENCE_SET:
        prediction = model.predict(image)
        if prediction.label == expected:
            correct += 1
        total += 1

    accuracy = correct / total
    VALIDATION_ACCURACY.set(accuracy)

    if accuracy < 0.95:
        alert(f"Model accuracy dropped to {accuracy:.1%} — retrain needed")

Grafana Dashboard

Key panels for the edge AI fleet dashboard:

1. Fleet Overview — map or table showing all devices, status, model version
2. Inference Performance — latency p50/p95/p99 per device, aggregated
3. Model Confidence Distribution — histogram showing confidence spread (drift = left shift)
4. Hardware Health — GPU temp, utilization, memory across fleet
5. Defect Rate Trend — is the defect detection rate changing? Could indicate model issue OR real quality issue
6. Alert Timeline — recent alerts with severity

Monitoring edge AI is harder than monitoring cloud services because devices fail in ways cloud servers don’t — dirty cameras, power fluctuations, physical damage. Build your dashboards with these failure modes in mind.
