Self-Service Infrastructure with Crossplane: Kubernetes-Native Cloud Management

The Promise: Infrastructure as Kubernetes Resources

What if developers could create a PostgreSQL database the same way they create a Kubernetes deployment? No Terraform, no tickets, no waiting. Just kubectl apply:

apiVersion: database.example.com/v1alpha1
kind: PostgreSQLInstance
metadata:
  name: my-service-db
  namespace: team-payments
spec:
  version: "16"
  storageGB: 50
  region: eu-west-1
  backups:
    enabled: true
    retentionDays: 30

That’s Crossplane. It extends Kubernetes to manage cloud resources using the same API, RBAC, and GitOps workflows your team already knows.

How Crossplane Works

Developer (kubectl apply)
    ↓
Kubernetes API Server
    ↓
Crossplane Controller
    ↓
Cloud Provider API (AWS/GCP/Azure)
    ↓
Actual cloud resource provisioned

Crossplane has three layers:

1. Providers — plugins for each cloud (AWS, GCP, Azure, etc.)
2. Managed Resources — 1:1 mappings to cloud resources
3. Compositions — platform team’s abstractions over managed resources

Building the Platform Layer

Step 1: Install Crossplane

helm repo add crossplane-stable https://charts.crossplane.io/stable
helm install crossplane crossplane-stable/crossplane \
  --namespace crossplane-system \
  --create-namespace

Step 2: Install a Provider

apiVersion: pkg.crossplane.io/v1
kind: Provider
metadata:
  name: provider-aws
spec:
  package: xpkg.upbound.io/upbound/provider-family-aws:v1.15.0

Step 3: Create a Composition (the abstraction)

This is where the platform team adds value — hiding cloud complexity behind simple interfaces:

apiVersion: apiextensions.crossplane.io/v1
kind: Composition
metadata:
  name: postgresql-production
spec:
  compositeTypeRef:
    apiVersion: database.example.com/v1alpha1
    kind: PostgreSQLInstance
  resources:
    - name: rds-instance
      base:
        apiVersion: rds.aws.upbound.io/v1beta1
        kind: Instance
        spec:
          forProvider:
            engine: postgres
            engineVersion: "16"
            instanceClass: db.t4g.medium
            allocatedStorage: 50
            storageEncrypted: true
            multiAz: true
            backupRetentionPeriod: 30
            vpcSecurityGroupIdSelector:
              matchLabels:
                type: database
            dbSubnetGroupNameSelector:
              matchLabels:
                type: private
          providerConfigRef:
            name: aws-production
      patches:
        - fromFieldPath: spec.storageGB
          toFieldPath: spec.forProvider.allocatedStorage
        - fromFieldPath: spec.version
          toFieldPath: spec.forProvider.engineVersion

    - name: secret
      base:
        apiVersion: kubernetes.crossplane.io/v1alpha2
        kind: Object
        spec:
          forProvider:
            manifest:
              apiVersion: v1
              kind: Secret
              metadata:
                namespace: "" # patched
              type: Opaque
      patches:
        - fromFieldPath: metadata.namespace
          toFieldPath: spec.forProvider.manifest.metadata.namespace

Now developers get a production-grade RDS instance with encryption, multi-AZ, backups, and proper networking — all from a 10-line YAML.

Crossplane vs Terraform

Crossplane isn’t replacing Terraform — I still use Terraform for foundational infrastructure (VPCs, accounts, IAM). See Terraform Pilot for those patterns. Crossplane handles the layer above: application-level resources that developers provision themselves.

RBAC: Who Can Create What

# Developers can create databases in their namespace
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  namespace: team-payments
  name: infra-consumer
rules:
  - apiGroups: ["database.example.com"]
    resources: ["postgresqlinstances"]
    verbs: ["get", "list", "create", "delete"]
  - apiGroups: ["cache.example.com"]
    resources: ["redisinstances"]
    verbs: ["get", "list", "create", "delete"]
  # No access to raw cloud resources

Developers can create databases but can’t modify VPCs, security groups, or IAM roles. The composition handles those details.

GitOps Integration

Crossplane + ArgoCD = fully declarative, auditable infrastructure:

# ArgoCD Application for team infrastructure
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: team-payments-infra
spec:
  source:
    repoURL: https://gitlab.com/teams/payments/infrastructure
    path: crossplane/
    targetRevision: main
  destination:
    server: https://kubernetes.default.svc
    namespace: team-payments
  syncPolicy:
    automated:
      selfHeal: true
      prune: true

Infrastructure changes go through PRs, get reviewed, and sync automatically. Full audit trail in Git.

Monitoring Crossplane Resources

Use the same Kubernetes monitoring stack — Prometheus + Grafana. I detail the setup at Kubernetes Recipes:

# Alert on failed resource provisioning
- alert: CrossplaneResourceNotReady
  expr: |
    kube_customresource_status_condition{
      group=~".*example.com",
      status="False",
      condition="Ready"
    } == 1
  for: 10m
  labels:
    severity: warning

The Self-Service Vision

The end state: developers ship infrastructure alongside their code. No tickets, no waiting, no context switching between “writing code” and “requesting infrastructure.” The platform team maintains the compositions, guardrails, and golden paths. Everyone moves faster.
