Ansible Conjur Tutorial: Secrets with cyberark.conjur

Ansible Conjur integration means your playbooks fetch passwords and keys from CyberArk Conjur at run time, so nothing secret sits in Git, not even encrypted. In this tutorial I run Conjur Open Source with the official Docker Compose quickstart, load a policy that gives the Ansible control node its own host identity and access to one database password, read that password with the cyberark.conjur.conjur_variable lookup, prove it never appears in ansible-playbook -v output, and rotate it. At the end I compare the approach with Ansible Vault and the HashiCorp Vault lookups.

At CfgMgmtCamp 2025 in Ghent I sat in on James Freeman’s talk on integrating Ansible with CyberArk Conjur. One thing he stressed in the clip I recorded is that a Conjur account isn’t a person: “accounts are the top level object in the hierarchy”, the container for every variable, policy and user. He’d named his first one after himself and only later understood why that felt odd. His “Things I learned” slides are the reason I wanted to rebuild the setup on a laptop, a year and a half and several collection releases later. Everything below is my own lab, not his demo; his own demo code is in ansible-conjur-integration-demo on GitHub.

Versions. I tested everything here with Conjur Open Source 1.24.0 (cyberark/conjur:latest from the quickstart), Conjur CLI 9.3.1 (cyberark/conjur-cli:9), the cyberark.conjur collection 1.3.14 from Galaxy, ansible-core 2.21.4 and Python 3.13 on macOS. The collection needs ansible-core 2.17 or later.

How the Ansible Conjur lookup authenticates

Four Conjur objects matter here:

• Account: the top-level namespace (myConjurAccount in the quickstart).
• Host: a machine identity with its own API key. The Ansible control node gets one.
• Variable: a secret, versioned. Each variable set adds a new version.
• Permit: a policy statement. read lets a role see the variable’s metadata, execute lets it fetch the value.

The conjur_variable lookup runs on the control node, like every Ansible lookup. It authenticates as a host with an API key, gets a short-lived access token, and calls GET /secrets/{account}/variable/{id}. It reads its settings from Ansible variables, from environment variables (CONJUR_APPLIANCE_URL, CONJUR_ACCOUNT, CONJUR_AUTHN_LOGIN, CONJUR_AUTHN_API_KEY, CONJUR_CERT_FILE), or from two files: /etc/conjur.conf (YAML) and /etc/conjur.identity (netrc format). Since 1.3.11 it also supports JWT and certificate authentication, and since 1.3.6 AWS, Azure and GCP. I use the API key here because it works on a laptop.

Run Conjur Open Source with Docker Compose

The conjur-quickstart repository is CyberArk’s demo environment. Its README states it is for demos only and must not be used for production. I start only the five services I need and skip pgAdmin and the sample bot app:

git clone https://github.com/cyberark/conjur-quickstart.git
cd conjur-quickstart
docker compose pull database conjur proxy client

# The data key encrypts secrets in Postgres. Keep it in a file, not on screen.
docker compose run --no-deps --rm conjur data-key generate > data_key
export CONJUR_DATA_KEY="$(< data_key)"

docker compose up -d database openssl conjur proxy client
docker compose exec conjur conjurctl wait -r 30
docker compose exec conjur conjurctl account create myConjurAccount > admin_data

admin_data now holds the admin API key. Connect the CLI container to the server through the nginx proxy and log in as admin, pasting the key from admin_data when prompted:

docker compose exec client conjur init oss -u https://proxy -a myConjurAccount --self-signed
docker compose exec client conjur login -i admin

The proxy publishes HTTPS on localhost:8443 with a self-signed certificate whose SANs include localhost, proxy and 127.0.0.1, so Ansible on the host can reach it at https://localhost:8443.

Load a policy for the Ansible control node

Create conf/policy/ansible.yml (the quickstart mounts conf/policy into the client container as /policy):

# Loaded into the root policy: creates everything under "ansible/"
- !policy
  id: ansible
  body:
    # Machines that run ansible-playbook
    - !layer controllers

    # The identity of the Ansible control node
    - !host control-node

    - !grant
      role: !layer controllers
      member: !host control-node

    # Enrol more controllers later without the admin key
    - !host-factory
      id: controllers
      layers: [ !layer controllers ]

    # The secret the playbook needs
    - !variable db/password

    # read = see metadata, execute = fetch the value
    - !permit
      role: !layer controllers
      privileges: [ read, execute ]
      resource: !variable db/password

Permissions go to the layer, not the host, so every controller you add to the layer later gets the same access. Load it and store the output in a file, because it contains the new host’s API key:

docker compose exec client conjur policy load -b root -f /policy/ansible.yml > ansible_policy_out.json

{
  "created_roles": {
    "myConjurAccount:host:ansible/control-node": {
      "id": "myConjurAccount:host:ansible/control-node",
      "api_key": "<HOST_API_KEY>"
    }
  },
  "version": 1
}

Now set the database password. I generate a throwaway value so it never appears in my shell history in clear text:

docker compose exec client conjur variable set -i ansible/db/password -v "demo-$(openssl rand -hex 8)"

Configure the control node

Install ansible-core and the collection in a virtualenv:

python3 -m venv venv
./venv/bin/pip install ansible-core
./venv/bin/ansible-galaxy collection install cyberark.conjur -p ./collections

Fetch the server certificate. This is the same openssl s_client approach James showed on his prep slide:

openssl s_client -showcerts -connect localhost:8443 </dev/null 2>/dev/null \
  | sed -ne '/-BEGIN CERTIFICATE-/,/-END CERTIFICATE-/p' > conjur.pem

Then give the lookup its identity through environment variables. Put them in a file with mode 0600 and source it; don’t type the key on the command line:

# conjur.env
export CONJUR_APPLIANCE_URL=https://localhost:8443
export CONJUR_ACCOUNT=myConjurAccount
export CONJUR_AUTHN_LOGIN=host/ansible/control-node
export CONJUR_AUTHN_API_KEY=<HOST_API_KEY>
export CONJUR_CERT_FILE=/path/to/conjur.pem

Note the host/ prefix on the login and the full policy path ansible/control-node. Without the prefix, Conjur looks for a user with that name, and the lookup failed with HTTP Error 401: Unauthorized.

Fetch the secret with cyberark.conjur.conjur_variable

ansible.cfg and inventory.ini:

# ansible.cfg
[defaults]
collections_path = ./collections
inventory = inventory.ini

# inventory.ini
[local]
localhost ansible_connection=local ansible_python_interpreter="{{ ansible_playbook_python }}"

The playbook, site.yml:

- name: Configure the app with a database password from Conjur
  hosts: local
  gather_facts: false
  tasks:
    - name: Fetch the password once
      ansible.builtin.set_fact:
        db_password: "{{ lookup('cyberark.conjur.conjur_variable', 'ansible/db/password') }}"
      no_log: true

    - name: Render the app config
      ansible.builtin.copy:
        dest: "{{ playbook_dir }}/out/app.env"
        content: "DB_PASSWORD={{ db_password }}\n"
        mode: "0600"
      no_log: true

    - name: Show that we have a value, without printing it
      ansible.builtin.debug:
        msg: "Got a {{ db_password | length }}-character password from Conjur"

The lookup term is the variable path without the account and without URL encoding. The plugin encodes ansible/db/password to ansible%2Fdb%2Fpassword itself.

$ mkdir -p out && source conjur.env && ansible-playbook site.yml

TASK [Fetch the password once] *************************************************
ok: [localhost]

TASK [Render the app config] ***************************************************
changed: [localhost]

TASK [Show that we have a value, without printing it] **************************
ok: [localhost] => {
    "msg": "Got a 21-character password from Conjur"
}

PLAY RECAP *********************************************************************
localhost                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0

A slide from James Freeman’s Ansible and Conjur talk at CfgMgmtCamp 2025: the “Playbook Run” of his demo, with “Get user name” and “Get host name” tasks and a debug message on a managed node.

Why set_fact and not play vars? A lookup inside vars: is lazy: Ansible evaluates it every time the variable is used. I put the same lookup in play vars and used it in three tasks. With -vvvv, the log showed three Conjur Variable URL requests. The set_fact version above made one.

Keep the secret out of ansible-playbook -v output

no_log: true is the part people forget. To check it, I read the real value into a shell variable and counted how often it appeared in each log:

SECRET=$(docker compose exec -T client conjur variable get -i ansible/db/password)
for v in "" -v -vvv -vvvv; do
  ansible-playbook site.yml $v > "run$v.log" 2>&1
  echo "flag[$v] hits=$(grep -cF "$SECRET" "run$v.log")"
done

site.yml scored 0 at every verbosity, and so did a search for the host API key. At -vvvv the plugin logs the variable URL, and the two no_log tasks show "censored": "the output has been hidden due to the fact that 'no_log: true' was specified for this result".

Then I removed no_log and passed the password on a command line, which is the common way it slips out:

$ ansible-playbook leak.yml -v
TASK [Fetch the password (no no_log)] ******************************************
ok: [localhost] => {"ansible_facts": {"db_password": "<THE-SECRET>"}, "changed": false}

TASK [Use it on a command line (no no_log)] ************************************
ok: [localhost] => {"changed": false, "cmd": ["test", "-n", "<THE-SECRET>"], ...}

Two hits with a single -v, and zero without it, which is why this survives code review: the default output looks clean. Fetching the secret from Conjur doesn’t protect you from Ansible printing it.

Rotate the secret and re-run

Rotation is a new version of the variable. Nothing changes in the playbook or the inventory:

docker compose exec client conjur variable set -i ansible/db/password -v "demo-$(openssl rand -hex 8)"
ansible-playbook site.yml

Render the app config went from ok on the run before the rotation to changed on the run after it, and back to ok on the next run. Earlier values remain readable by version with conjur variable get -i ansible/db/password --version 1. Whatever consumes app.env still needs a handler or restart to pick up the new password; Conjur doesn’t push anything.

Config files instead of environment variables

Environment variables suit CI. On a long-lived control node, the lookup’s defaults are /etc/conjur.conf and /etc/conjur.identity, which you can relocate with CONJUR_CONFIG_FILE and CONJUR_IDENTITY_FILE:

# /etc/conjur.conf
account: myConjurAccount
appliance_url: https://localhost:8443
cert_file: /etc/conjur.pem

# /etc/conjur.identity (netrc format, mode 0600)
machine https://localhost:8443/authn
  login host/ansible/control-node
  password <HOST_API_KEY>

The machine line must be the appliance URL plus /authn, or the plugin fails with “The netrc file on the controlling host does not contain an entry for”. With both files in place and every CONJUR_* variable unset, site.yml ran unchanged.

James Freeman’s “Grant” slide: the cyberark.conjur.conjur_host_identity role applied to the control host, with the host factory token read from an environment variable.

The collection’s conjur_host_identity role writes exactly those files (/etc/conjur.conf, /etc/conjur.identity and /etc/conjur.pem) and installs Summon. In the talk James said the role stores the CA certificate under /etc itself, so you only need to put the downloaded PEM somewhere temporary for it to pick up. I didn’t run the role in this lab, because it needs a Linux target and become.

Enrol more controllers with a host factory token

The !host-factory in the policy lets a pipeline create new hosts in the controllers layer with a short-lived token instead of the admin key:

docker compose exec client conjur hostfactory tokens create --duration 15m -i ansible/controllers
docker compose exec client conjur hostfactory hosts create -i ci-runner-01 -t <HOST_FACTORY_TOKEN>

The second command returns an API key for host/ci-runner-01. With that login and key, the same lookup fetched ansible/db/password, because the factory added the host to the layer that holds the permit. Note the host ID: in my test the factory created ci-runner-01 at the top level, not under ansible/.

The “Prep” slide from the same talk: install the collection, fetch the server certificate with openssl s_client, and create a host factory token with a masked value.

TLS: what changed since the talk

James Freeman’s “Things I learned” slide at CfgMgmtCamp 2025.

His slide said the lookup plugin “currently fails to verify the TLS certificate of the Conjur server if you use LetsEncrypt/ACME”, and listed three workarounds: turn off TLS verification (“not good”), export CONJUR_CERT_FILE pointing at the system CA bundle, or extract the whole CA chain into /etc/conjur.pem. The first bullet matches the plugin code: the lookup takes its identity from Ansible variables, environment variables or /etc/conjur.identity, never from a CLI session.

The collection changelog has since fixed the TLS side. Release 1.3.7 (August 2025) fixed TLS verification failing when the Conjur certificate was issued by a trusted CA, and 1.3.13 (July 2026) fixed CA bundle files and allows validate_certs=true with no explicit certificate when the CA is in the system trust store. In 1.3.14, when you pass a certificate, the plugin writes a temporary bundle of the system CAs plus your PEM and verifies against that.

With a self-signed lab certificate you still need CONJUR_CERT_FILE. Without it the lookup failed immediately with CERTIFICATE_VERIFY_FAILED ... self-signed certificate. Passing validate_certs=false worked but printed Certificate validation has been disabled. Leave validation on.

Pitfalls I hit

• 404 for everything. A variable that exists but isn’t permitted to your host returns the same HTTP Error 404: Not Found as one that doesn’t exist. Conjur doesn’t reveal resources you can’t see. Check the permit and the layer membership before checking the spelling.
• A 40-second failure. The plugin retries failed variable requests five times, 10 seconds apart, and a 404 counts. My missing-variable test took 41 seconds. Set conjur_retry_interval (an Ansible variable) lower while you develop; with -e conjur_retry_interval=1 it failed in under 5 seconds.
• Lazy lookups in vars hit Conjur once per use, as shown above.
• macOS: the first run died with “A worker was found in a dead state” until I exported OBJC_DISABLE_INITIALIZE_FORK_SAFETY=YES. That’s a macOS fork-safety issue, not a Conjur one.
• as_file=true returns a path to a 0600 temporary file (in /dev/shm when it’s writable), which is the way to feed an SSH private key to ansible_ssh_private_key_file.

Ansible Conjur vs Ansible Vault vs HashiCorp Vault

For HashiCorp Vault, the equivalent call is lookup('community.hashi_vault.vault_kv2_get', 'db', engine_mount_point='secret').secret.password: the lookup returns a dictionary, and secret holds the key/value data. My Ansible Vault tutorial and the SOPS with Ansible guide cover the in-repo options.

My take: if your organisation already runs CyberArk, use Conjur and give each controller and CI runner its own host identity through a layer, so revoking one runner doesn’t touch the others. If you’re choosing from scratch for a small team, SOPS or Ansible Vault is less to operate. Whichever you pick, the -v test above is worth adding to CI, because the leak comes from Ansible’s output, not from the secret store.
