AI Observability: Tracing LLM Calls with OpenTelemetry

The Black Box Problem

Your AI feature is slow. Users complain about wrong answers. Costs spiked 3x last week. But you can’t explain why because LLM calls are opaque — you know the input and output but nothing about what happened in between.

This is the observability gap that kills AI products.

OpenTelemetry for LLMs

OpenTelemetry (OTel) is the standard for distributed tracing. It works for LLM applications too — with some AI-specific instrumentation.

Basic LLM Tracing

from opentelemetry import trace
from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter

# Setup
provider = TracerProvider()
provider.add_span_processor(BatchSpanProcessor(OTLPSpanExporter()))
trace.set_tracer_provider(provider)
tracer = trace.get_tracer("ai-service")

class TracedLLMClient:
    def __init__(self, client):
        self.client = client

    async def generate(self, messages, model="gpt-4o"):
        with tracer.start_as_current_span("llm.generate") as span:
            span.set_attribute("llm.model", model)
            span.set_attribute("llm.provider", "openai")
            span.set_attribute("llm.input_tokens", self._estimate_tokens(messages))

            start = time.monotonic()
            response = await self.client.chat.completions.create(
                model=model,
                messages=messages
            )
            latency = time.monotonic() - start

            # Record metrics
            span.set_attribute("llm.output_tokens", response.usage.completion_tokens)
            span.set_attribute("llm.total_tokens", response.usage.total_tokens)
            span.set_attribute("llm.latency_ms", int(latency * 1000))
            span.set_attribute("llm.cost_usd", self._calculate_cost(model, response.usage))
            span.set_attribute("llm.finish_reason", response.choices[0].finish_reason)

            return response

Agent Workflow Tracing

For multi-step agent workflows, nest spans to see the full execution tree:

async def agent_workflow(self, user_query):
    with tracer.start_as_current_span("agent.workflow") as root:
        root.set_attribute("user.query", user_query[:200])

        # Step 1: Planning
        with tracer.start_as_current_span("agent.plan"):
            plan = await self.planner.create_plan(user_query)

        # Step 2: Execute steps
        for i, step in enumerate(plan.steps):
            with tracer.start_as_current_span(f"agent.step.{i}") as step_span:
                step_span.set_attribute("step.type", step.type)
                step_span.set_attribute("step.tool", step.tool_name)

                if step.type == "llm_call":
                    result = await self.traced_llm.generate(step.messages)
                elif step.type == "tool_call":
                    with tracer.start_as_current_span("tool.execute"):
                        result = await self.tools.execute(step.tool_name, step.params)

        # Step 3: Synthesize
        with tracer.start_as_current_span("agent.synthesize"):
            final = await self.synthesize(results)
            root.set_attribute("agent.total_steps", len(plan.steps))
            root.set_attribute("agent.total_cost", self.accumulated_cost)

        return final

In Jaeger or Grafana Tempo, this renders as a trace tree showing exactly where time and tokens were spent.

Key Metrics to Track

Cost Tracking

# Cost per model (as of 2026, update regularly)
COST_PER_1K_TOKENS = {
    "gpt-4o": {"input": 0.0025, "output": 0.01},
    "gpt-4o-mini": {"input": 0.00015, "output": 0.0006},
    "claude-opus-4": {"input": 0.015, "output": 0.075},
    "claude-sonnet-4": {"input": 0.003, "output": 0.015},
}

def calculate_cost(model, usage):
    rates = COST_PER_1K_TOKENS.get(model, {"input": 0, "output": 0})
    input_cost = (usage.prompt_tokens / 1000) * rates["input"]
    output_cost = (usage.completion_tokens / 1000) * rates["output"]
    return round(input_cost + output_cost, 6)

Quality Signals

# Track response quality indicators
span.set_attribute("quality.has_code", bool(re.search(r'```', response_text)))
span.set_attribute("quality.response_length", len(response_text))
span.set_attribute("quality.contains_apology", 'sorry' in response_text.lower())
span.set_attribute("quality.finish_reason", finish_reason)  # 'stop' vs 'length' (truncated)

Grafana Dashboard

For the monitoring stack setup, I use the same Prometheus + Grafana patterns I detail at Kubernetes Recipes. Key panels:

Row 1: Overview
  - Total LLM calls/min
  - Total cost (rolling 24h)
  - P95 latency
  - Error rate

Row 2: Cost Breakdown
  - Cost by model (pie chart)
  - Cost by feature (bar chart)
  - Cost trend (7-day line)
  - Projected monthly cost

Row 3: Performance
  - Latency by model (heatmap)
  - Token usage distribution
  - Cache hit rate
  - Rate limit events

Row 4: Quality
  - Finish reason distribution
  - Average response length trend
  - User feedback scores
  - Retry rate

Automating with Ansible

For teams deploying the OTel collector across multiple environments, I use Ansible playbooks to standardize the setup. The infrastructure-as-code approach I teach at Ansible Pilot applies directly — treat your observability stack like any other managed service:

- name: Deploy OTel collector for AI services
  hosts: ai_services
  roles:
    - role: otel-collector
      vars:
        exporters:
          - type: otlp
            endpoint: tempo.monitoring:4317
          - type: prometheus
            endpoint: "0.0.0.0:8889"
        processors:
          - type: batch
            timeout: 5s
          - type: attributes
            actions:
              - key: environment
                value: production
                action: upsert

The ROI of AI Observability

Without observability:

• Debugging a bad AI response: 2-4 hours (reproduce, guess, retry)
• Finding cost spikes: manual bill review, days later
• Explaining AI behavior to stakeholders: impossible

With observability:

• Debugging: 5 minutes (trace the exact request)
• Cost spikes: real-time alerts
• Explainability: “here’s the trace showing every step the AI took”

Instrument from day one. The cost of adding observability later is 10x the cost of building it in.
