AI Gateway on Kubernetes: Route and Load-Balance LLM Traffic

What Is an AI Gateway?

An AI gateway sits between your application and LLM providers, adding:

• Intelligent routing — send requests to the best model/provider
• Load balancing — distribute across GPU pools
• Fallback — automatic failover when a provider is down
• Rate limiting — protect backends from traffic spikes
• Cost tracking — per-request cost attribution
• Caching — semantic deduplication of similar queries

┌──────────┐     ┌─────────────────┐     ┌──────────────┐
│  Client  │────▶│   AI Gateway    │────▶│  vLLM Pool   │
│  Apps    │     │                 │────▶│  NIM Pool    │
│          │     │  • Route        │────▶│  OpenAI API  │
│          │     │  • Rate limit   │────▶│  Anthropic   │
│          │     │  • Cache        │     └──────────────┘
│          │     │  • Track cost   │
└──────────┘     └─────────────────┘

Architecture on Kubernetes

Option 1: Envoy + AI-Specific Filters

apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: ai-gateway
spec:
  gatewayClassName: envoy
  listeners:
    - name: ai-api
      protocol: HTTPS
      port: 443
---
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: ai-routes
spec:
  parentRefs:
    - name: ai-gateway
  rules:
    # Route to fast model for simple queries
    - matches:
        - headers:
            - name: x-model-tier
              value: fast
      backendRefs:
        - name: vllm-8b
          port: 8000
    # Route to quality model for complex queries
    - matches:
        - headers:
            - name: x-model-tier
              value: quality
      backendRefs:
        - name: vllm-70b
          port: 8000
    # Weighted traffic split (canary)
    - backendRefs:
        - name: vllm-70b
          port: 8000
          weight: 90
        - name: nim-70b
          port: 8000
          weight: 10

Option 2: LiteLLM Proxy

LiteLLM provides a unified OpenAI-compatible API across 100+ LLM providers:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: litellm-proxy
spec:
  replicas: 3
  template:
    spec:
      containers:
        - name: litellm
          image: ghcr.io/berriai/litellm:main-latest
          ports:
            - containerPort: 4000
          env:
            - name: LITELLM_MASTER_KEY
              valueFrom:
                secretKeyRef:
                  name: litellm-secrets
                  key: master-key
          volumeMounts:
            - name: config
              mountPath: /app/config.yaml
              subPath: config.yaml
      volumes:
        - name: config
          configMap:
            name: litellm-config

# litellm-config.yaml
model_list:
  - model_name: "gpt-4-turbo"
    litellm_params:
      model: "openai/gpt-4-turbo"
      api_key: "os.environ/OPENAI_API_KEY"

  - model_name: "llama-70b"
    litellm_params:
      model: "openai/meta-llama/Llama-3.1-70B-Instruct"
      api_base: "http://vllm-70b.ai-inference:8000/v1"
      api_key: "dummy"

  - model_name: "llama-70b"  # Second backend for load balancing
    litellm_params:
      model: "openai/meta-llama/Llama-3.1-70B-Instruct"
      api_base: "http://nim-70b.ai-inference:8000/v1"
      api_key: "os.environ/NGC_API_KEY"

router_settings:
  routing_strategy: "least-busy"
  num_retries: 3
  timeout: 60
  fallbacks:
    - model_name: "llama-70b"
      fallback: "gpt-4-turbo"

general_settings:
  master_key: "os.environ/LITELLM_MASTER_KEY"
  database_url: "os.environ/DATABASE_URL"

Routing Strategies

Rate Limiting

Per-User Token Budget

# Envoy rate limit config
apiVersion: v1
kind: ConfigMap
metadata:
  name: ratelimit-config
data:
  config.yaml: |
    domain: ai-gateway
    descriptors:
      - key: user_id
        rate_limit:
          unit: hour
          requests_per_unit: 100  # 100 requests/hour per user
      - key: user_id
        descriptors:
          - key: model_tier
            value: "quality"
            rate_limit:
              unit: hour
              requests_per_unit: 20  # Only 20 quality-tier requests/hour

Token-Based Rate Limiting (LiteLLM)

litellm_settings:
  max_budget: 100.0  # $100/month per API key
  budget_duration: "1mo"

  # Per-model limits
  model_max_budget:
    gpt-4-turbo: 50.0
    llama-70b: 30.0

Semantic Caching

Cache responses for semantically similar queries:

import hashlib
from qdrant_client import QdrantClient

cache_db = QdrantClient(host="qdrant-cache.ai-inference.svc")

async def semantic_cache_lookup(query: str, threshold: float = 0.95):
    query_embedding = await embed(query)

    results = cache_db.search(
        collection_name="response_cache",
        query_vector=query_embedding,
        limit=1,
        score_threshold=threshold,  # Only return if >95% similar
    )

    if results:
        return results[0].payload["response"]  # Cache hit!
    return None  # Cache miss — proceed to LLM

Impact: 20-40% of requests hit cache in production (FAQ, repeated queries, similar phrasings).

Cost Attribution

Track spend per team/project/user:

# Custom metrics for cost tracking
from prometheus_client import Counter, Histogram

tokens_used = Counter(
    'ai_gateway_tokens_total',
    'Total tokens consumed',
    ['model', 'team', 'direction']  # direction: input/output
)

request_cost = Histogram(
    'ai_gateway_request_cost_dollars',
    'Cost per request',
    ['model', 'team'],
    buckets=[0.001, 0.01, 0.05, 0.1, 0.5, 1.0, 5.0]
)

Grafana Cost Dashboard

# Cost per team per day
sum by (team) (increase(ai_gateway_request_cost_dollars_sum[24h]))

# Most expensive model
topk(5, sum by (model) (rate(ai_gateway_request_cost_dollars_sum[1h])) * 3600)

# Token efficiency (output/input ratio)
sum(rate(ai_gateway_tokens_total{direction="output"}[1h])) /
sum(rate(ai_gateway_tokens_total{direction="input"}[1h]))

Failover Configuration

# Automatic failover chain
router_settings:
  fallbacks:
    - model_name: "llama-70b"      # Primary: self-hosted
      fallback: "gpt-4-turbo"       # Fallback: OpenAI

  retry_policy:
    num_retries: 2
    retry_after_seconds: 1
    retry_on_status_codes: [429, 500, 502, 503]

  # Health check backends
  health_check:
    enabled: true
    interval_seconds: 30
    unhealthy_threshold: 3
